Front View

Control Lamps
Display Window
Keyboard
Connector for optional
paper cutter
(Not used in this printer model)
Print Unit
Front Door
Intermec EasyCoder 501 XP – User's Guide
The front door is held by a snap-lock. Open the front door to
view the various parts on the printer's front.
Refer to Chapter 9 "Options" for information on possible optional
devices fi tted on the printer's front.
Chapter 2 Installation
9
