Front View

At the front of the printer are the display window, the control lamps, and
the control keys. These features allow the operator to control and set up
the printer manually as described later in this chapter.
The printed labels, tickets, or tags are presented at the front of the print
mechanism. The front cover can be removed for loading of labels at peel-
off (self-strip) operation and for installation of a cutter (options).
Control lamps
LCD display
(some models
only)
Control keys
Front cover
Intermec EasyCoder PD4—User's Guide
Chapter 2—Installation
Side door with
inspection window
7
