b. Plot Pattern Test — (Figure 4–33)
1. Load printer with full width single part paper.
2. Set Exerciser controls as follows:
LINE LENGTH = 132
CHARACTER = DELETE
SPECIAL = PLOT MODE
FUNCTION = LINE FEED
3. Place printer on line. Print one half page and take printer off line.
4. Examine the printout and compare to Figure 4–33.
4–72
continued
Figure 4–33. Plot Pattern Test
