Printronix p300 Maintenance Manual page 148

FROM SHEET 3
Replace shuttle
motor per para 5–31.
Print out and check for
symptom.
Symptom
present
YES
Install orginal shuttle
motor per para 5–31.
Replace paper feed
motor per para 5–35.
Print out and check
for symptom.
Symptom
present
YES
Refer to schematics
and troubleshoot
using standard
techniques. If problem
remains, contact
authorized distributor
service
representative.
4–42
C
NO
Normal operation
?
NO
Normal operation
?
Figure 4–18. Misplaced Dots (4 of 4)
Return to
Return to
P300/P600 Troubleshooting
