P300/P600 Troubleshooting
Ribbon folds
over.
Clean ribbon path.
Operate printer and
observe ribbon.
NO
Still
folds over
?
YES
Adjust spool hubs and
ribbon guides per para
5–3 and 5–4.
Operate printer and
observe ribbon.
NO
Still
folds over
?
YES
Refer to schematics
and troubleshoot
using standard
techniques. If problem
remains, contact
authorized distributor
service
representative.
Figure 4–8. Ribbon Folds Over
Return to
Normal operation
Return to
Normal operation
4–17
