The LAN Interface

LAN Interface Port
1. Ethernet 10/100BaseT Connector
2. Green 10/100Mbit/sec. Transmission Speed LED
3. Yellow Traffic LED

LED indicators

The LED indicator modes are described in the following table:

Environmental requirements

The printer operates correctly in environments that are typical of most business
offices.
Attention: Damage to the printer can occur if you power on (|) the printer
immediately after the printer has been moved from an environment that does not
meet the following operating requirements. If the printer has been in such a
location, be sure that you move the printer to the correct operating environment at
least 24 hours before you power on (|) the printer.

Operating environment

The following table shows the operating environment requirements for the printer.
Note: The best conditions for feeding and stacking are within a temperature range

Shipping environment

The following table shows the shipping environment requirements for the printer.
Note: You must cover the printer with a plastic cover for shipping.
Table 31. RS232/C serial interface signals (continued)
Signal Pin Connect.
Name Number
DTR 4
LED Status Description
Yellow Unlit Transmission speed at 10Mbit/sec.
LED
Lit Transmission speed at 100Mbit/sec.
Green Blinks Transmitting or receiving packets from the network.
LED
Environment
Temperature range
Relative humidity range
of 15.6 to 32.2°C (60 to 90°F) and a relative humidity range of 26 to 62%.
Local Remote
Connect.
Source Source Description
Printer Printer Data Terminal Ready. Normally HIGH
(ON). Indicates that the printer is ready to
initiate a connection.
Requirement
10° to 40° C (50° to 104°F)
10% to 90% RH (non-condensing)
Appendix A. Printer specifications
169
