Rear Automatic Forms Thickness Adjustment (Afta); Rear Tear Position - Compuprint X03 User Manual

5. Press ENTER to display the current value.
6. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for
7. Press ENTER.
8. Press START or RETURN to exit the Menu. See "Exiting the Configuration

Rear Automatic Forms Thickness Adjustment (AFTA)

This parameter allows you to adjust the distance between the paper and the
printhead for the rear forms path. Forms must be loaded for this adjustment to be
effective. This adjustment can be set to one of the following values:
-5 to +3
Fixed 1 to 8
Default = 0
To change or check the Rear AFTA:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
5. Press ENTER to display the current value.
6. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for Rear
7. Press ENTER.
8. Press START or RETURN to exit the Menu. See "Exiting the Configuration

Rear Tear Position

You can adjust the rear tear position for forms loaded in the rear paper path from
-390 to +30 (where each unit is 0.176 mm [1/144 in.]). The default value is 0.
To change or check the Rear Tear Position:
1. Press MENU.
118
User's Guide
Printer Adjustments
Front Form Load Position
Front Paper Load Position is displayed.
An asterisk (*) is displayed in front of the selected value.
Menu" on page 39.
The printer automatically adjusts the distance between the forms
and the printhead. Each adjustment corresponds to 0.03 mm (.0012
in.). (The default is 0, which corresponds to a gap of 0.25 mm [.01
in.] from the forms.)
Selects a fixed printhead distance value from 1 to 8 in increments
of 0.5 (where each value equals approximately 0.05 mm [.002 in.]).
CONFIGURATION MENU
Printer Adjustments
Printer Adjustments
Rear AFTA
AFTA is displayed.
An asterisk (*) will be displayed in front of the selected value.
Menu" on page 39.
