Chapter 9. Printer adjustments
Paper-Load-Position to Tear-Position relationship
Front Automatic Forms Thickness Adjustment
(AFTA)
.
.
.
.
.
.
Front Tear Position
.
.
Front Left Margin Alignment .
Front Paper Load Position .
Rear Automatic Forms Thickness Adjustment
(AFTA)
.
.
.
.
.
.
This chapter describes the procedures for checking and changing the Printer
Adjustment parameters. The Printer Adjustments appear in both the Configuration
Menu and in the Operator Print Tests Menu. In the Configuration Menu, the
values can be set but not tested. In the Operator Print Tests, the adjustments can be
set and then tried by running a print test. (See Chapter 17, "Using the Operator
Print Tests.") Printer adjustment parameters can be set for each paper source: Front
and Rear.
This chapter is divided into sections according to parameter. Refer to the partial
table of contents above for parameter and page listings.
Paper-Load-Position to Tear-Position relationship
There are Paper Load Position parameters for each forms path. These Paper Load
Position settings are used to vertically align printing on the forms. An example is
to center printing in a box on a preprinted form.
Whenever one of these Paper Load Position parameters is set, the printer
automatically adjusts the corresponding Tear Position value to compensate for the
change you made to the Load Position. This automatic adjustment keeps the forms
perforation aligned to the tear bar edge when the form is ejected. However, if
further adjustment is needed in the alignment of the forms perforation to the tear
bar, you should adjust the Tear Position value.
The automatic adjustment changes the tear adjustment by the same number of
units but in the opposite direction. Normally this adjustment means that Tear
Position is set to the offsetting ("equal but opposite") value. Stated another way, if
the Load Position is set to +40, then the Tear Position is set to -40 (see example 1 in
the examples that follow). However, if the current setting of the Tear Position has
been changed by the operator to be different from the offsetting value, that
difference from the offsetting value is maintained by the printer (see example 2 in
the examples that follow).
Examples of how this works:
1. The current values in the printer are Front Paper Load Position = 0 and Front
2. The current values in the printer are Front Paper Load Position = +40 and
115
.
.
.
.
.
.
.
.
. 116
.
.
.
.
.
.
.
.
. 116
.
.
.
.
.
.
. 117
.
.
.
.
.
.
.
. 117
.
.
.
.
.
.
.
.
. 118
Tear Position = 0. The user sets Front Paper Load Position to +40. The printer
automatically sets Front Tear Position to -40.
Front Tear Position = -44. The user changes Front Paper Load Position to +50.
The printer automatically sets Front Tear Position to -54, maintaining the
difference of 4 from the normal offsetting value of "equal but opposite".
Rear Tear Position .
.
.
Rear Left Margin Alignment .
Rear Paper Load Position .
Bidirectional Adjustment
Sensor Tune .
.
.
.
.
Quit From Menu .
.
.
.
.
.
.
.
.
.
.
. 118
.
.
.
.
.
.
. 119
.
.
.
.
.
.
.
. 120
.
.
.
.
.
.
.
.
. 120
.
.
.
.
.
.
.
.
. 121
.
.
.
.
.
.
.
.
. 121
115
