Replacing The User Card Tray And Line Cable - AT&T MERLIN LEGEND Release 3.0 Installation Manual
Communications system
Hide thumbs
Also See for MERLIN LEGEND Release 3.0:
- System programming manual (818 pages) ,
- System programming and maintenance manual (128 pages) ,
- Programming summary manual (446 pages)
Table of Contents
Advertisement
Installing Multi-Function Modules
Deskstand
Telephonet
B a s e
Figure 3–17. Replacing the User Card Tray and Line Cable
10
Replace the user card tray and line cable. See Figure 3-17.
a Insert the user card tray at an angle, then lower and slide into the
deskstand.
b Replace the line cable into the line jack in the deskstand.
L i n e
C a b l e
Installing Telephones and Adjuncts 3-19
C a r d
Tray
