Processor Problems
CAUTION:
Grasping only one of the rings may cause damage to components on
the processor circuit board or feature module.
5
Check the HDR4 header on the processor circuit board for proper mode
operation. (For more information about modifying the mode, see Chapter
2 of Installation.)
Figure 4-5. Replacing the Feature Module
4-32 Control Unit Problems
