Installing Multi-Function Modules
Deskstand
Telephone
Base
Figure 3–17. Replacing the User Card Tray and Line Cable
10 Replace the user card tray and line cable. See Figure 3–17.
a Insert the user card tray at an angle, then lower and slide into the
deskstand.
b Replace the line cable into the line jack in the deskstand.
Line
Cable
Installing Telephones and Adjuncts
Card
Tray
3–19
