AT&T MERLIN LEGEND Release 3.0 Installation Manual page 425

Module Problems
Console Display/Instructions
2 Specify the slot number (nn = 00 to 17).
Slot:
Enter Slot number (00-17)
nn
Backspace
Exit
3 Select Demand Test.
Slot xx:
Make a selection
Status
Busy-out
Restore
Exit
4 Select Internal Loopback Test.
Demand Test Slot
Make a selection
Note: Busy out slot first
BoardCntrlr
IntLoopback
Exit
5. To run the test once or run it repeatedly, select Test Once or Repetitive.
Demand Test Slot
Board aaaaaaaaaaaaaaa
Internal Loopback
Test Once
Repetitive
Exit
Enter
Demand Test
Reset
Upgrade
:
XX
:
XX
Additional Information
Dial or type [ nn ], then press
xx = slot number entered in Step 2
For all MLX modules,
also displayed as an option on this
screen. For 100D modules,
and
Error Events, Clock
displayed as options on this screen.
xx = slot number entered in Step 2
xx = slot number entered in Step 2
Select or
Test Once
Repetitive
Control Unit Problems 4-47
PC
Enter.
is
BchLoopback
CSU-lpbk,
are also
(F5)
(F3)
(F2)
(F3)
