AT&T MERLIN LEGEND Release 3.0 Installation Manual page 461

100D Module Problems
The screen below displays the errors that have accumulated during the
current hour.
Console Display/Instructions
Current hr Slot
mm/dd/yy
CurAlm aaaa
MIS SLP ES
xxx xxx xxx xxx xxx xxx
Exit
The screen below displays the errors that have accumulated during the
previous hour.
Previous hr Slot xx:
mm/dd/yy
CurAlm aaaa
MIIS SLP ES BS SEC FS
xxx xxx xxx xxx xxx xxx
Exit
100D Module Clock Status
If you have not been trained to perform T1 maintenance, contact your
technical support organization for instructions on using this procedure.
Summary
Console Procedure
PC Procedure
:
XX
hh00-hh:mm
MaxAlm aaaa
BS SEC FS
hh:0O-hh:mm
MaxAlm aaaa
Menu → Maintenance → Slot → Dial slot no. →
Enter → Clock → Exit
(F6) → (F2) → Type slot no. → (F10) → (F9) → (F5)
Additional Information
xx = slot number entered in Step 2
xx = slot number entered in Step 2
Control Unit Problems 4-83
