Connecting a PC to the Control Unit
Figure 5-1. Connecting a PC Within 50 ft. (15.2 m)
SMDR
Jack
ADMIN
Jack
355AF
Adapter
D8W
Processor Module
EIA-232-D
Control Unit

Installing the PC, CAT, or Printer 5-3
