100D Module Problems

Upgrade Attempted on an Empty Slot
Console Display/Instructions
Upgrade Slot xx:
No module in slot.
Exit
Select and repeat the upgrade procedure, being careful to select the
Exit
correct slot.
Board Memory Programming Failure
Upgrade Slot xx:
Board Memory Programming
Failure.
Upgrade CANCELED.
Upgrade INCOMPLETE.
Exit
Repeat the upgrade procedure. If the upgrade continues to fail after several
attempts, the module should be replaced. See "Replacing the Module. "
100D Module Problems
The 100D module requires the CSU Loopback Test, in addition to the other
module tests, See Figure 4–6 for a diagram of the entire module testing
process. If you have any questions about the 100D module that this section
does not cover, contact your technical support organization.
4-70 Control Unit Problems
Additional Information
xx =
slot selected in Step 3.
xx = slot selected in Step 3.
