Error Logs
Table 2-2 Continued
Error
Codes Description
NOT IN STANDBY MODE:
7806
Reported during cold start or
background check.
7807 SELF TEST NOT COMPLETER
Reported during cold start.
7808 TEST RESULT REGISTER BAD:
A module error or processor error
resulted while running test.
TEST STATUS REGISTER BAD:
7809
A module error or processor error
resulted while running test.
780A DPR TEST NOT COMPLETED:
Reported during cold start.
780C RAM TEST FAILURE:
Memory failed the RAM test. Turns
on the processor LED.
780D UPPER ROM FAILURE:
Memory failed the ROM test. Turns
on the processor LED.
780E LOWER ROM FAILURE:
Memory failed the ROM test. Turns
on the processor LED.
2-14 Error Logs, Access Logs, and System Inventory
Action
Reset the board. If problem persists,
troubleshoot the module.
Reset the board. If problem persists,
troubleshoot the module.
Reset the board, If problem persists,
troubleshoot the module.
Reset the board. If problem persists,
troubleshoot the module.
If problem persists, troubleshoot the
module.
If problem persists, replace the
processor.
If problem persists, replace
processor.
If problem persists, replace the
processor.
Continued on next page
