Connecting a Printer to the Control Unit
Connecting a Printer 50 Feet
(15.2 m) or More Away
Use this procedure to connect a printer to the control unit if the following
conditions apply:
The printer is not a CAT printer connected to a CAT.
The printer is 50 ft. (15.2 m) or more from the control unit.
The printer is not grounded to the same AC outlet as the control unit.
The printer is not grounded to an outlet that is on the same
117-V AC branch as the control unit and that is 50 ft. (15.2 m) or closer
to the control unit.
NOTE:
If you are installing the printer in a different room than the control unit, make
sure that both locations have working wall outlets and wall jacks, and that the
building wiring has been connected so that the wall jacks in each location
communicate with each other.
You need the following hardware for this procedure:
Z200A EMI filter
Adapter for the interface cable connector
— 355A for the male connector
— 355AF for the female connector
400B2 power adapter
Z3A2 ADUs
BRIA-4P adapter or 102 connecting block or 103 connecting block
8-position wall jacks
EIA crossover cable
ADU crossover cable
2012D transformer
