AT&T MERLIN LEGEND Release 3.0 Installation Manual page 491

Checking Ports
Console Display/Instructions
2 Specify the RS-232 port.
Port:
Make a Selection
Line/Trunk
Station
RS232 Portl
RS232 Port2
Exit
3 Select Reset.
RS232 Port x:
Make a selection
Reset
Exit
4 Select Yes.
RS232 Port x Reset:
Do you want to continue?
Yes
Cancel
Exit
The screen below is shown until Reset finishes or fails.
RS232 Port x Reset:
Reset in Progress
Exit
Modem
B-Channel
Enter
Additional Information
Select or
RS232 Port1
RS232 Port2.
x = port selected in Step 2
x = port selected in
Step 2
x = port selected in
Step 2
Central Office Problems 5-21
P C
(F3)
(F4)
(F1)
(F2)
