Checking System and Slot Status
If a slot is empty,
empty, according to the sample screen in the last procedure.
Slot Status
Slot Status provides the following information for a module in a particular
LED status
Errors (yes or no)
Mode (initialization, standby, test, or normal)
Alarms (yes or no)
Maintenance busy (yes or no)
Summary
Console Procedure:
PC Procedure
To check Slot Status, follow the steps below.
Console Display/Instructions
1 From the Maintenance menu, select the Slot option.
Maintenance
Make a selection
System
Slot
Port
Exit
and appear without indicating a status. Slot 4 is
R, Y, G
Menu → Maintenance → Slot → Dial the slot no.
→ Enter → Status
(F6) → (F2) → Type the slot no. → (F10) → (F1)
Additional Information
Control Unit Problems 4-89
slot:
PC
(F2)
