AT&T MERLIN LEGEND Release 3.0 Installation Manual page 430

Module Problems
Console Display/Instructions
5 Select Test Once or Repetitive.
Demand Test Slot xx:
aaaaaaaaaaaaaaaaa
Board
Board Controller:
Test once
Repetitive
Exit
The screen below appears
module has a green LED, it
Demand Test Slot xx:
aaaaaaaaaaaaaaaaa
Board
Board Controller Test
in Progress
Exit
The screen below appears only if you selected
passes the test.
Demand Test Slot xx:
Board aaaaaaaaaaaaaaaaa
Board Controller Test
Successfully Completed
Exit
The screen below appears when either test
Demand Test Slot xx:
aaaaaaaaaaaaaaaaa
Board
Board Controller Test
FAILED
xxxxxxxxxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxxxxxx
Exit
4-52 Control Unit Problems
Additional Information
xx = slot number entered in Step 2
while the test is running. At the same time, if the
flashes.
xx = slot number entered in Step 2
If you are running the repetitive test,
this screen remains until the test fails.
To interrupt repetitive testing, select
Exit.
Test Once
xx = slot number entered in Step 2
(Once
xx = slot number entered in Step 2
Lines 5 and 6 show error messages.
If there are more than two messages,
select More
and the module
or fails.
Repetitive)
to see them.
PC
(F2)
(F3)
(F5)
(PgUp)
