Error Logs
Table 2-2 Continued
Error
Codes Description
0012 INVALID RESET FLAG:
Processor problem.
0013 DUART STREAMING INT:
Processor problem.
0014 PROCESSOR ERR INTERRUPT:
Processor problem.
0015 MODULE MISMATCH:
Physical and logical type mismatch.
Module inserted into wrong slot.
0016 POWER UP COLD START:
A module dual port RAM failure was
detected.
System programming is okay.
0C01 NO I-VMS PORT IN SERV:
This error indicates that the VMS
machine may be down.
0C02 DID INTERDIGIT TIMEOUT:
May be noisy line or central office
problem.
1CO1 POOL M-BUSY EXCEEDS 50%:
More than half the trunks in the pool are
busy.
1C02 FW UPGRADE ATTEMPT
2-8 Error Logs, Access Logs, and System Inventory
Action
Troubleshoot the processor.
Troubleshoot the processor.
Troubleshoot the processor.
Change system programming to reflect
the proper module or install the proper
module.
If problem persists, troubleshoot the
module for the slot, indicated.
No action required.
No action required. If problem persists,
troubleshoot the DID line and inform the
central office if necessary.
Troubleshoot trunk.
If FW UPGRADE ATTEMPT is logged and FW
UPGRADE COMPLETE is not, the firmware
upgrade should be retried. The circuit
module should be considered unreliable
until a successful upgrade is performed.
Continued on next page
