AT&T MERLIN LEGEND Release 3.0 Installation Manual page 424

Module Problems
Busy-Out or Reset
Interrupting the Test
Test Failure
Restore
To run the Internal Loopback Module Test, follow the steps below.
Console Display/Instructions
1 From the Maintenance menu, select the Slot option.
Maintenance
Make a selection
System
Slot
Port
Exit
4-46 Control Unit Problems
Busy-out or reset the module being tested prior to
beginning the test. Both Busy-Out and Reset are in
the Slot menu, which you can access by doing the
following from the console:
Menu → Maintenance → Slot
See "Busy-Out and Reset," earlier in this chapter,
for additional information.
You can interrupt the test (both
by selecting
Repetitive)
If the test fails, record the errors on the repair tag
and replace the module.
Restore the module if it successfully completes all
module tests and the errors no longer occur.
is in the Slot menu, which you can access
Restore
by doing the following from the console:
Menu → Maintenance → Slot
See the "Restore" procedure, earlier in this chapter,
for additional information.
Additional Information
and
Test Once
Exit.
PC
(F2)
