Error Logs
Table 2-2 Continued
Error
Codes Description
1C03 FW UPGRADE COMPLETE
3001 ALARM TABLE FULL:
The error logs are full, and no more
errors can be added to them.
Turns on the processor LED.
4401
USER REQUESTED SYS ERASE:
This error is logged after a System
Erase. If the System Erase is
successful, this error is removed
immediately.
6C01 DS1 LOSS OF SIGNAL ALARM:
Service on the link has been lost.
6C02
DS1 BLUE ALARM:
All ones being received
the link has been lost.
6C03 DS1 RED ALARM:
Incoming signal does not have valid
framing information.
Service on the link has been lost.
Action
No action required.
Correct indicated errors, and then
remove entries from the transient system
error log to free up space. If problem
persists, cold-start the system before
continuing with troubleshooting.
Sys Program → → System-Restart
If this error remains in the transient log,
do the System Erase again. If problem
persists, troubleshoot the processor.
Troubleshoot the T1 trunk. If problem
persists, check the channel service unit
(CSU) and the cable between the CSU
and the 100D module. If problem
persists, escalate to your technical
support organization.
The far end of the network interface is out
Service on of service. Troubleshoot the T1 trunk,
channel service unit (CSU), and the
cable between the CSU and the 10OD
module. If problem persists, escalate to
your technical support organization.
Troubleshoot the T1 trunk. If problem
persists, escalate to your technical
support organization.
Error Logs, Access Logs, and System Inventory 2-9
Continued on next page
