The SPM Display

SPM screens simulate the MLX-20L console (see Figure 1-4).
V2
Home
QUIT
End
MENU
LINE
Shift
05
F 5
Shift
LINE
04
F4
LINE
Shift
03
F3
Shift LINE
02
F 2
Shift
F1
Figure 1-4. The SPM Display
Each SPM screen includes a 7-line by 24-character console simulation
window that corresponds to the display area of the MLX-20L telephone. To the
right and left of this console simulation window are columns, listing the keys
that correspond to similarly located buttons on the MLX-20L telephone.
The 10 function keys, identified on screen as (F1) through (F10) , are used to
select screen options. When a screen displays several choices, press the
function key identified by the label next to your choice. (If you were working
on the console you would press the telephone button next to your choice.)
Below the console simulation window are 20 simulated line buttons. Using
(PgDn) (Inspect), you can determine the status of each line.
