Once you have entered the IP address and SNMP information for the PathBuilder
S700 on the VT100 terminal, you can continue configuring the device on the local
console, or you can configure the PathBuilder S700 through either the 10BaseT or
the SLIP/PPP dialup port on the Management CPU module using either a Telnet
session or an SNMP manager such as PathBuilder Switch Manager. See Figure 35.
Figure 35 PathBuilder S700 Terminal Access Methods
SNMP
160.160.1.1
160.160.1.3
Telnet
160.160.1.2
SLIP or PPP
SNMP
or
Telnet
160.160.1.4
Configuring the Local Host IP Address
The Local Host IP Address Configuration menu allows you to set parameters for
the management port (Ethernet or SLIP) or the PathBuilder S700.
To enter configure the Ethernet management port, follow these steps:
1 From the Manage IP Network Configuration menu, select [1] Local Host IP
Configuration to display the Local Host IP Configuration menu, shown in
Figure 36.
When you apply a change to the Local Host IP Configuration menu, you might get
logged out if you are using a Telnet session. The default configuration is Baud rate:
9600, Parity; none, Data Bits:8, StopBits:1.
PathBuilder S700
Mgmt
10BaseT
Module
Dialup
RS 232
Port
Direct
Mask 255.255.255.0
Performing Initial Configuration
SNMP
ATM
160.160.1.5
Telnet
160.160.1.6
RS 232
VT100
9600 Bps
