5
Viewing and
Configuring System
Information
C
ONFIGURING
M , P
ODULES
This chapter tells you how to configure the modules, circuits, and related
applications supported by the PathBuilder S700 WAN access switch
(PathBuilder S700) so that the device can pass traffic. It contains the following
sections:
Viewing and Configuring System Information
n
PathBuilder S700 Configuration Overview
n
Configuring the PathBuilder S700 Shelf and the Application Modules
n
Configuring the Shelf
n
Configuring the Management CPU
n
Configuring Virtual Interfaces
n
Configuring Input Shapers
n
Configuring the STX Module
n
Configuring OC3/STM-1 UNI Modules
n
Configuring DS3 UNI Modules
n
Configuring E3 UNI Modules
n
Configuring DS1 UNI or E1 UNI with IMA Modules
n
Configuring Ethernet Modules
n
Configuring DSX-1 CBR or E1 CBR Modules
n
Configuring QSIM/HSIM/FAM Modules
n
Configuring Virtual Circuits
n
The System Administration menu, shown in Figure 72, includes options that allow
you to view and configure system information. In addition to using this menu for
initial configuration, as described in Chapter 3, you can:
Specify general system information.
n
Manage the system clock.
n
View system parameters for the RS-232 ports.
n
View the current firmware version.
n
Download new firmware.
n
Update the flash file system.
n
Reset the interface card.
n
View an equipment list.
n
The following subsections describe these System Administration menu options.
P B
ATH UILDER
,
ORTS AND
S700
A
PPLICATIONS
