Once you have connected the QSIM, verify the front panel indicators. As shown in
Figure 18, in addition to the common system front panel indicators, each port has
a pair of LEDs to the left of the port.
ENBL—Illuminates when the port is in service.
CLK—Illuminates when clocking is in service.
Figure 18 QSIM LEDs
Slot 1
Step 4: Connect I/O Cabling and Wiring
Slot 18
CLK
43
Power On
Inservice
Fail
Test
ENBL
PORT 4
PORT 3
60-Pin
Amphenol
Connectors
PORT 2
PORT 1
