Conforming/Non-Conforming Cell Counters

The conforming and non-conforming cells reflect a cell's ingress types (CLP0 or
CLP1) prior to any policing actions. These counters do not count a cell more than
once. If a cell is received as a CLP0 type and is then tagged due to policing, the cell
will still be counted as a CLP0 cell.
The following subsections provide additional information that applies to the
conforming and non-conforming cell counters, depending on which policing
configuration you choose.
Conforming/Non-Conforming Cell Counters for CBR Traffic
Config 1
Conf CLP0 = Conforming CLP0 cells
Conf CLP1 = Ingress CLP1 cells
Nonconf CLP0 = Non-conforming CLP0 cells that were tagged
Nonconf CLP1 = not counted
Config 2
Conf CLP0 = Conforming CLP0 cells
Conf CLP1 = Conforming CLP1 cells
Nonconf CLP0 = Non-conforming CLP0 cells that were dropped
Nonconf CLP1 = Non-conforming CLP1 cells that were dropped
Total dropped cell count = Received - Sent
Conforming/Non-Conforming Cell Counters for Non-CBR Traffic
Config 1
Conf CLP0 = Conforming CLP0 cells
Conf CLP1 = Conforming CLP1 cells
Nonconf CLP0 = Non-conforming CLP0 cells that were tagged and/or dropped
Nonconf CLP1 = Non-conforming CLP1 cells that were dropped
Tagged cell count = Sent CLP1 - Conf CLP1
Total dropped cell count = Received - Sent
Total dropped by policing = ((Received - Sent) - Dropped (due to congestion))
Config 2
Conf CLP0 = Conforming CLP0 cells
Conf CLP1 = Conforming CLP1 cells
Nonconf CLP0 = Non-conforming CLP0 cells that were tagged
Nonconf CLP1 = Non-conforming CLP1 cells that were dropped
Tagged cell count = Sent CLP1 - Conf CLP1
Total dropped cell count = Received - Sent
Total dropped by policing = ((Received - Sent) - Dropped (due to congestion))
