Configuring UNI and
IMA Groups
P B S700 M
ATH UILDER ODULES
Table 33 Bit Error Rates Translated into Total Number of Errors
Bit
Error
Rate Total Errors
(BER) in 1 second
-4
10 15
-5
10 1.5
-6
10 0.15
10 -7 0.015
Group—The number of the group to which the ports belong.
Admin. Status—Administrative status: Out of Service or In Service.
Operation Status—Operation status: Response or No Response.
5 Select [13] Previous Menu to return to the DSI UNI Configuration menu.
6 Repeat steps 4 and 5 for any other DS1 or E1 ports that you want to configure.
You can map two to eight DS11/E1 ports into an IMA group, thereby creating a
logical, inverse-multiplexed, high-speed link. The PathBuilder S700 also supports
UNI groups.

Adding UNI Groups

To set up a UNI group, follow these steps:
1 From the Configuration Management menu, shown earlier in Figure 80, select
[1] Manage Card.
2 From the List Card menu, shown earlier in Figure 81, select the number
corresponding to the slot in which the DS1 UNI or E1 UNI card is installed to open
the DS1 or E1 UNI Configuration menu, shown earlier in Figure 95.
3 From the DS1 or E1 UNI Configuration menu, select [3] Group Configuration to
display the Group menu, shown in Figure 99.
, P , A
ORTS AND PPLICATIONS
Total Errors
Total Errors in 2
in 1 Minute Minutes
900 1800
90 180
9 18
1 2
Total Errors Total Errors
in 5 in 15
Minutes Minutes
4500 13500
450 1350
45 135
5 13
