2.28 LAN EMULATION CLIENT ADMINISTRATION SCREEN

The LEC Administration screen is used to modify the management LAN Emulation Client
(LEC). A new LEC can be configured by the user, or this function can be performed
automatically by the SmartSwitch 9500.
To access the LEC Administration screen from the LAN Emulation Client Menu screen,
perform the following steps:
1. Use the arrow keys to highlight the ADMIN menu item from the LAN Emulation Client
Menu screen.
2. Press ENTER; the LAN Emulation Client Administration screen,

2.28.1 LAN Emulation Client Administration Screen Fields

The following list explains each of the LAN Emulation Client Administration Screen fields
and commands:
LEC Index (Read-only)
Used to identify this LEC in the ATM Forum's LEC MIB. This value is provided dynamically
and is not modifiable by the user.
LEC Status (Toggle)
Displays the current status of this LEC. This field toggles between "active" or "Not In
Service".
9A656-04/9A686-04 Configuration Guide
Figure 2-30 LAN Emulation Client Administration Screen
LAN Emulation Client Administration Screen
Figure 2-30, displays.
2-63
