CTM interfaces may be recognized by the following CTM ANIM #:
• If the ANIM number of the interface numbering scheme is 08 through 15.
For example, if the interface number is 11402. This means that the 9A686-04 is installed
in slot 1. The CTM ANIM is number 14, and it is port 2 of that CTM ANIM that has the
connection.
The CTM ANIMs have two ports.
NOTE
1.5

DEFAULT SETTINGS UPON FIRST INITIALIZATION

The 9A686-04, upon first initialization, performs a series of pre-configured setup procedures.
These procedures set up a default configuration of the switch that allows the device to begin
functioning in the network immediately. No setup is required by the user except the
assignment of an IP address for management purposes. This provides the 9A686-04 with
plug-and-play capabilities.

1.5.1 9A686-04 Initialization Steps

The 9A686-04 performs the following procedures when they are first inserted into a powered
up SmartSwitch 9500 chassis.
1. The 9A686-04 assigns itself an ATM address.
ATM address.
13 Byte NSAP Prefix
47-000000-000000-0000-1D123456-00001D123456-00
Default 9 Byte NSAP Prefix
Based on the Default PNNI
Level of 72
9A656-04/9A686-04 Configuration Guide
Least Significant 4 Bytes of
Base Mac Address/ESI
Figure 1-1 Default ATM Address Breakdown
Default Settings Upon First Initialization
Figure 1-1 provides an example of a default
End System
Identifier (ESI)
Selector Byte
Page 1-7
