Chapter 4: Signalling and Routing
4.5.1.2

Step 2: Set the IISP Side

The IISP Signalling stack type must be set before setting the side of the interface.
NOTE
The next step in configuring IISP is to assign which side of UNI the individual front panel
interface will use for the connection, (network or user). This is accomplished using the
atmIntfConfigSide command. Refer to Figure 4-5.
A
B
C
Figure 4-5 Setting the Signalling Side
Figure 4-5 contains 3 callouts that display status information, and the configuration fields
necessary to set the Signalling side. The definitions for the callouts are as follows:
A
This section of the screen displays the name of the MIB command used to perform this
procedure (atmIntfConfigSide) and the OID string the SNMP application is using to access
this information (1.3.6.1.2.1.37.14.1.14.1.3).
