Chapter 2: System Configuration
Screen Update Time (Modifiable)
Contains the rate at which the screens are updated. This setting determines how frequently (in
seconds) information is updated on the screen. To enter a new update time, refer to
Section 2.6.4.
SAVE (Command)
Saves all changes to memory.

2.6.1 Setting the IP Address

The following instructions describe how to set the In-Band IP Address, the SMB-10
NOTE
IP Address, and the Out-Of-Band IP Address.
Section 2.6.1
the SmartSwitch 9500. Save time by setting all desired configurations, and then
TIP
using the arrow keys to highlight the SAVE command at the bottom screen and
pressing ENTER.
To set the IP address, perform the following steps:
1. Use the arrow keys to highlight the desired IP Address field.
2. Enter the IP address into this field using Decimal Dotted Notation (DDN) format.
For example: 134.141.79.120
3. Press ENTER. If the IP address is a valid format, the cursor returns to the beginning of the
IP address field. If the entry is not valid, the Event Message Line displays "INVALID IP
ADDRESS OR FORMAT ENTERED". Local Management does not alter the current
value and refreshes the IP address field with the previous value.
DO NOT set the In-Band IP Address to the same value as the SMB-10 or
!
Out-Of-Band IP Address.
CAUTION
The SMB-10 and Out-Of-Band IP Address may be set to the same value.
4. Use the arrow keys to highlight the SAVE command, then press ENTER. The "SAVED
OK" message displays indicating that the changes have been saved to memory.
2-8
through Section 2.6.4 provide instructions on configuring settings for
9A656-04/9A686-04 Configuration Guide
