Cabletron Systems 9A656-04 Configuration Manual page 78

Chapter 2: System Configuration
SOURCE VPI ENTRY (Modifiable)
Used to enter the VPI of the source end of the SPVC. If the 9A686-04 is using the default
ILMI settings, the available range for this field is between 33 and 4095.
If the ILMI settings have been changed from the default values, the available range
NOTE
of this field depends on the current ILMI settings. Refer to
Chapter 3 for more information on ILMI.
SOURCE VCI ENTRY (Modifiable)
Used to enter the VCI of the source end of the SPVC. If the 9A686-04 is using the default
ILMI settings, the available range for this field is between 33 and 16k.
If the ILMI settings have been changed from the default values, the available range
NOTE
of this field depends on the current ILMI settings. Refer to
Chapter 3 for more information on ILMI.
SOURCE ATM ADDRESS (Modifiable)
Used to enter the ATM Address of the source end of the SPVC or SPVP.
DESTINATION VPI ENTRY (Modifiable)
Used to enter the VPI of the destination end of the SPVC. Any information entered in this field
MUST also be assigned to the device that will support the destination end of the SPVC.
Ensure that the device that will support the destination end of the SPVC can
NOTE
support the VPI value entered in this field. If the destination device is another
9A686-04, refer to
VPI/VCIs.
DESTINATION VCI ENTRY (Modifiable)
Used to enter the VCI of the destination end of the SPVC. Any information entered in this
field MUST also be assigned to the device that will support the destination end of the SPVC.
Ensure that the device that will support the destination end of the SPVC can
NOTE
support the VCI value entered in this field. If the destination device is another
9A686-04, refer to
VPI/VCIs.
DESTINATION ATM ADDRESS (Modifiable)
Used to enter the ATM Address of the source end of the SPVC or SPVP.
ATOM Persistence is: (Read-only)
Displays the current setting of ATOM Persistence. This will display "ON" or "OFF". "ON"
signifies that in the event that the 9A686-04 module or SmartSwitch 9500 chassis is reset, the
SPVC or SPVP will still exist after boot up. "OFF" signifies that if the module or chassis is
reset, the SPVC or SPVP will be lost upon boot up. The default setting for this field is "ON".
2-48
Section 2.17 and Chapter 3
Section 2.17 and Chapter 3
Section 2.17
Section 2.17
for information on ILMI and available
for information on ILMI and available
9A656-04/9A686-04 Configuration Guide
