  • Page 1 9A656-04 and 9A600 Configuration Guide 9032598-01...

  • Page 3: Fcc Notice

    WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Printed on Recycled Paper 9A656-04 and 9A600 Configuration Guide...

  • Page 4: Doc Notice

    TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND THE LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND. 9A656-04 and 9A600 Configuration Guide...
  • Page 5 Acquisition Regulations, Section 52.227-7013 (c) (1) (ii) and its successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at 252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505. 9A656-04 and 9A600 Configuration Guide Notice...

  • Page 6: Safety Information

    Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter. SAFETY INFORMATION CLASS 1 LASER TRANSCEIVERS SAFETY INFORMATION CLASS 1 LASER TRANSCEIVERS watts. 9A656-04 and 9A600 Configuration Guide Notice...

  • Page 7: Declaration Of Conformity

    Mr. Ronald Fotino ___________________________________ Full Name Principal Compliance Engineer ___________________________________ Title Rochester, NH, USA ___________________________________ Location 9A656-04 and 9A600 Configuration Guide DECLARATION OF CONFORMITY 89/336/EEC 73/23/EEC Manufacturer’s Name: Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr.
  • Page 8 Notice 9A656-04 and 9A600 Configuration Guide...

  • Page 9: Table Of Contents

    Setting the IP Address ... 2-9 2.5.2 Setting the Chassis Date... 2-9 2.5.3 Setting the Chassis Time ... 2-10 2.5.4 Entering a New Screen Update Time... 2-11 SNMP Community Names Screen ... 2-12 2.6.1 Establishing Community Names ... 2-13 9A656-04 and 9A600 Configuration Guide CONTENTS...
  • Page 10 LAN Emulation Client Administration Screen Fields... 2-50 2.23.2 Configuring the LEC Automatically... 2-51 2.23.3 Configuring the LEC Manually... 2-52 2.24 Network Tools ... 2-53 2.24.1 Built-in Commands ... 2-55 2.24.2 Special Commands ... 2-60 viii 9A656-04 and 9A600 Configuration Guide...
  • Page 11 4.3.1 PNNI Overview... 4-7 4.3.2 Peer Groups... 4-8 4.3.3 Crankback ... 4-9 4.3.4 GCAC... 4-10 4.3.5 Addressing ... 4-10 IISP Overview ... 4-10 4.4.1 Supported UNI Signalling Versions... 4-10 4.4.2 UNI Sides ... 4-10 9A656-04 and 9A600 Configuration Guide Contents...
  • Page 12 B.1.7 PNNI Settings ... B-2 B.1.8 Clocking... B-2 B.1.9 Maximum Number of Connections ... B-2 APPENDIX C SUPPORTED MIBS C.1 MIB, SMI, MIB Files and Internet MIB Hierarchy ... C-1 C.2 SmartSwitch 9500 MIB Hierarchy... C-3 9A656-04 and 9A600 Configuration Guide...

  • Page 13: Chapter 1 Introduction

    “SmartSwitch 9500 chassis” which indicates a SmartSwitch 9000 chassis with one or more 9A656-04 or 9A600 ATM SmartSwitch modules installed. Unless noted differently, this guide applies to both the 9A656-04 and 9A600 ATM SmartSwitch modules, which are referred to as the “9A656-04”.

  • Page 14: Document Conventions

    , provides information on how the , provides information and instructions on how to use , provides information on the default settings the SmartSwitch , provides tables that detail all of the MIB branches and branch 9A656-04 and 9A600 Configuration Guide...

  • Page 15: Overview

    CTM backplane. The CTM provides a dedicated 1.6 Gbps link between each 9A656-04 module. The 9A600 is a 5.4 Gbps, single slot module for the SmartSwitch 9500 chassis. Up to four ATM Network Interface Modules (ANIMs) of any type can be installed in the 9A600 to provide front panel connectivity to the network.

  • Page 16: Atm Traffic Types

    AToM MIB (RFC 1695) • AToM II MIB • ILMI MIB • PNNI MIB • Cabletron MIBs • SFCS MIB • ctNetwork MIB • ctPIC MIB • ctFlash MIB • nwRouter MIB • ctron Mib2 MIB Ext. 9A656-04 and 9A600 Configuration Guide...

  • Page 17: Distributed Clocking

    The LEC automatically joins the default ELAN. Although all modules in the chassis are capable of becoming the LEC, only one LEC is active in the system at one time. This is accomplished through a LEC election algorithm. 9A656-04 and 9A600 Configuration Guide...

  • Page 18: Interface (Port) Numbering

    1. The CTM ANIM is number 14, and it is port 2 of that CTM ANIM that has the connection. The CTM ANIMs have two ports. NOTE CTM interface numbering does not apply to the 9A600. Slot 3 Slot 7 Slot 11...

  • Page 19: Default Settings Upon First Initialization

    (via the default NSAP prefix and level) and will not produce multiple Nodes with the same Node ID (via the unique base MAC address). 9A656-04 and 9A600 Configuration Guide Default Settings Upon First Initialization Figure 1-1...
  • Page 20 If there are multiple 9A656-04s in the chassis, an election process occurs where one of the modules is elected to handle all management requests to the SmartSwitch 9500 chassis. The 9A656-04 begins switching traffic. Connections and their bandwidth requirements are accepted on a first come, first served basis. 9A656-04 and 9A600 Configuration Guide...

  • Page 21: Additional Default Settings

    The 9A656-04 is set to be in Clock Recovery Mode, which means that all clocking will be recovered from the received signals. 9A656-04 and 9A600 Configuration Guide Default Settings Upon First Initialization 1-2. With this default setting, the SmartSwitch 9500 is an...

  • Page 22: Configurable Options

    Chassis Power Supply Information (Read-only Screen) Local Management provides access to the Chassis Power screen. This screen contains current information on the status of all power supplies installed in the SmartSwitch 9500 chassis. 1-10 9A656-04 and 9A600 Configuration Guide...
  • Page 23 The SmartSwitch 9500 chassis can be set to run ATM diagnostics when power is cycled or the modules are reset. All major hardware subsystems of the system are tested during the power up diagnostics. 9A656-04 and 9A600 Configuration Guide 1-11...

  • Page 24: Local Management Screen Elements

    This field briefly displays messages that indicate if a Local Management procedure was executed correctly or incorrectly, that changes were saved or not saved to Non-Volatile Random Access Memory (NVRAM), or that a user did not have access privileges to an application. 1-12 9A656-04 and 9A600 Configuration Guide...
  • Page 25 In the screens shown in this guide, the characters in this field are all upper case and in bold type. In the field description, the field is identified as being a “command” field. 9A656-04 and 9A600 Configuration Guide Local Management Screen Elements Table 1-4 Event Messages What it Means One or more fields were...

  • Page 26: Local Management Keyboard Conventions

    For example, “Use the arrow keys” means to press whichever arrow key moves the cursor to the desired field on the Local Management screen. 9A656-04 and 9A600 Configuration Guide Table 1-5 explains the keyboard...

  • Page 27: Getting Help

    GETTING HELP For additional support related to this device or document, contact the Cabletron Systems Global Call Center: Phone Internet mail Login Password For additional information about Cabletron Systems or its products, visit the World Wide Web site: http://www.cabletron.com/ To send comments or suggestions concerning this document, contact the Cabletron Systems Technical Writing Department via the following email address: TechWriting@cabletron.com Make sure to include the document Part Number in the email message.
  • Page 28 Use the following manuals to supplement the procedures and other technical data provided in this manual. Cabletron Systems 9A656-04 Hardware and Installation Guide Cabletron Systems 9A600 Hardware and Installation Guide Cabletron Systems SmartSwitch 9000 Operations Guide Cabletron Systems SmartSwitch 9000 9C300-1 Environmental Module User’s Guide Cabletron Systems SmartSwitch 9000 Local Management User’s Guide...

  • Page 29: Chapter 2 Basic System Configuration

    (Section All references to the CTM backplane or CTM interfaces apply ONLY to the 9A656-04 ATM SmartSwitch module, as the 9A600 does not connect to the CTM backplane. This chapter describes the basic procedures that may be performed at the system level to allow the SmartSwitch 9500 chassis to begin functioning in the network immediately.

  • Page 30: Navigating Local Management Screens

    ILMI CONFIGURATION Figure 2-1 Local Management Screen Hierarchy Section 1.7. Password Main Menu ENVIRONMENTAL MODULE NETWORK TOOLS MODULE SPECIFIC CONFIGURATION SYSTEM CONFIGURATION MODULE CONFIGURATION ATM DIAGS PORT STATUS 9A656-04 and 9A600 Configuration Guide Figure 2-1 LANE CLIENT PORT ERRORS PROPERTIES ADMIN...

  • Page 31: Selecting Local Management Menu Screen Items

    Exit from Local Management by repeating steps 1 or 2 until the Main Menu screen displays. Use the arrow keys to highlight the RETURN command at the bottom of the Main Menu screen. Press ENTER. The Password screen displays and the session ends. 9A656-04 and 9A600 Configuration Guide Navigating Local Management Screens...

  • Page 32: Accessing The Main Menu Screen

    To access the Main Menu screen, establish a Local Management connection. The Password Screen, Figure 2-2, displays. To proceed to the Main Menu screen enter the community name “public” or press ENTER, the Main Menu screen, Figure 2-3, displays. Figure 2-2 The Password Screen 9A656-04 and 9A600 Configuration Guide...

  • Page 33: The Main Menu Screen

    The Environmental Module menu item provides access to the Environmental Module screen. This screen allows you to set the COM port applications, view chassis fan tray status, download a new image to Flash memory, and to check the chassis temperature and the external temperature. 9A656-04 and 9A600 Configuration Guide...

  • Page 34: The Chassis Menu Screen

    Access is limited based on the password level of the user. For details, refer to the Figure 2-4, displays Figure 2-4 The Chassis Menu Screen Section 9A656-04 and 9A600 Configuration Guide 2.5. Section 2.6.

  • Page 35: Chassis Power

    CHASSIS CONFIGURATION option and pressing ENTER. The Chassis Configuration screen displays. Figure 2-5 Chassis Configuration Screen The following list briefly describes each of the Chassis Configuration screen fields: MAC Address (Read-only) Displays the base physical address of the chassis. 9A656-04 and 9A600 Configuration Guide...

  • Page 36: Save (Command)

    Contains the rate at which the screens are updated. This setting determines how frequently (in seconds) information is updated on the screen. To enter a new update time, refer to Section 2.5.4. SAVE (Command) The SAVE command saves all changes to memory. Section 2.5.2. 2.5.3. 9A656-04 and 9A600 Configuration Guide 2.5.1.

  • Page 37: Setting The Ip Address

    It is not necessary to add separators between month, day, and year numbers. For NOTE example, to set the date to 05/17/1998, type “05171998” in the Chassis Date field. 9A656-04 and 9A600 Configuration Guide Section 2.5.4 provide instructions on configuring settings for...

  • Page 38: Setting The Chassis Time

    “SAVED OK”. If the entry is not valid, Local Management does not alter the current value and refreshes the Chassis Time field with the previous value. Upon saving the new chassis time, all 9A656-04 modules installed in the chassis NOTE recognize the new value as the current time. 2-10 9A656-04 and 9A600 Configuration Guide...

  • Page 39: Entering A New Screen Update Time

    “SAVED OK”. If the entry is not valid, Local Management does not alter the current setting, but it does refresh the Screen Update Time field with the previous value. 9A656-04 and 9A600 Configuration Guide Chassis Configuration Screen 2-11...

  • Page 40: Snmp Community Names Screen

    Access the SNMP Community Names screen from the Chassis Menu screen by using the arrow keys to highlight the SNMP COMMUNITY NAMES field and pressing ENTER. The SNMP Community Names screen, Figure 2-6 The SNMP Community Names Screen 2-12 Figure 2-6, displays. 9A656-04 and 9A600 Configuration Guide...

  • Page 41: Establishing Community Names

    Use the arrow keys to highlight SAVE at the bottom of the screen and press ENTER. The message “SAVED OK” displays. The community names are saved to memory and their access modes implemented. 9A656-04 and 9A600 Configuration Guide SNMP Community Names Screen 2-13...

  • Page 42: Snmp Traps Screen

    (read-only, read-write or super-user) determines the types of traps sent to the network management station. Enable Traps (Toggle) Enables transmission of the traps to the network management station with the associated IP address. This field toggles between YES and NO. 2-14 9A656-04 and 9A600 Configuration Guide...

  • Page 43: Configuring The Trap Table

    YES (send alarms from the chassis to the workstation), or NO (prevent alarms from being sent). Using the arrow keys, highlight the SAVE field and press ENTER. The message “SAVED OK” displays on the screen. The designated workstations now receive traps from the chassis. 9A656-04 and 9A600 Configuration Guide SNMP Traps Screen 2-15...

  • Page 44: The Chassis Power Screen

    Displays the total amount, in watts, of chassis power that is currently available. Chassis Backplane Voltages (Read-only) Displays the values, in volts, of the power buses for the installed interface modules, the environmental module, and the INB terminators respectively. 2-16 9A656-04 and 9A600 Configuration Guide...
  • Page 45 To use this command use the arrow keys to highlight the PS2 command and press ENTER. The Power Supply Specific Section of the screen displays the values for power supply two. 9A656-04 and 9A600 Configuration Guide 2-17...

  • Page 46: The Module Selection Screen

    To select an individual module to perform Local Management functions, proceed as follows: Use the arrow keys to highlight the desired module in the Module Name field. Press ENTER. The applicable Module Menu screen displays. 2-18 Figure 2-9 The Module Selection Screen 9A656-04 and 9A600 Configuration Guide...

  • Page 47: The Module Menu Screen For The 9A656-04

    The Network Tools function resides on the 9A656-04 and consists of a series of commands that allow the user to access and manage network devices. Refer to instructions on how to use the network tools commands. 9A656-04 and 9A600 Configuration Guide The Module Menu Screen for the 9A656-04 Figure 2-10, displays.

  • Page 48: The Module Configuration Menu Screen

    The Module Specific Configuration Menu screen allows the user to set specific operating parameters for the 9A656-04, to view the current port status, to view any port errors that have occurred, and to configure the management LEC of the SmartSwitch 9500. For details, refer Section 2.13. 2-20 9A656-04 and 9A600 Configuration Guide...

  • Page 49: The General Configuration Screen

    Contains a value that the module recognizes as the current date. To set a new date refer to Section 2.5.2. Module Time (Modifiable) Contains a value that the module recognizes as the current time. To enter a new time, refer to Section 2.5.3. 9A656-04 and 9A600 Configuration Guide The General Configuration Screen Figure 2-12, displays. 2-21...
  • Page 50 Displays the base physical address of the module. TFTP Gateway IP Addr (Modifiable) Displays and allows the user to set the TFTP Gateway IP address for the 9A656-04. To set the TFTP Gateway IP address, refer to 2-22 Section 2.12.2. Section 2.12.3. 9A656-04 and 9A600 Configuration Guide...

  • Page 51: Entering A New Screen Refresh Time

    “SAVED OK”. If the entry is not valid, Local Management does not alter the current setting, but it does refresh the Screen Lockout Time field with the previous value. 9A656-04 and 9A600 Configuration Guide The General Configuration Screen...

  • Page 52: Setting The Tftp Gateway Ip Address

    Management does not alter the current value, but it does refresh the Default Gateway field with the previous value. Use the arrow keys to highlight the SAVE command. Press ENTER. The Event Message Line at the top of the screen displays “SAVED OK”. 2-24 9A656-04 and 9A600 Configuration Guide...

  • Page 53: Setting The Default Interface

    Management does not alter the current value, but it does refresh the Default Interface field with the previous value. Use the arrow keys to highlight the SAVE command. Press ENTER. The Event Message Line at the top of the screen displays “SAVED OK”. 9A656-04 and 9A600 Configuration Guide The General Configuration Screen 2-25...

  • Page 54: The Module Specific Configuration Screen

    9A656-04 that has been elected the chassis agent. The chassis agent module may be identified via the Module Selection screen (Section 2.9). For details on the System Configuration Menu screen, refer to Section 2.14. 2-26 9A656-04 and 9A600 Configuration Guide...

  • Page 55: System Configuration Menu Screen

    To access the System Configuration Menu screen, perform the following steps: Use the arrow keys to highlight the SYSTEM CONFIGURATION menu item from the Configuration Menu screen. Press ENTER. The System Configuration Menu screen, 9A656-04 and 9A600 Configuration Guide System Configuration Menu Screen Figure 2-14, displays.
  • Page 56 The ATM Diags menu item opens the Diags Configuration Menu screen. This screen is used to enable or diable the ATM diagnostics that the SmartSwitch 9500 performs when power is cycled, or the front panel RESET button is pressed. For details, refer to Section 2.17. 2-28 9A656-04 and 9A600 Configuration Guide...

  • Page 57: The Pnni Configuration Screen

    Use the arrow keys to highlight the PNNI CONFIGURATION menu item from the System Configuration Menu screen. Press ENTER. The PNNI Configuration screen, Figure 2-15 The PNNI Configuration Screen 9A656-04 and 9A600 Configuration Guide The PNNI Configuration Screen Figure 2-15,displays.

  • Page 58: Pnni Configuration Screen Fields

    Refer to Figure 2-30 End System Identifier (ESI) Non-Modifiable Least Significant 4 Bytes of Base Mac Address/ESI In this mode, the PNNI Level field is defaulted to 80. The user 2-17. 9A656-04 and 9A600 Configuration Guide Figure 2-16. Selector Byte...
  • Page 59 104, PNNI routing will see multiple nodes with the same prefix. This will cause PNNI to calculate paths to nodes that may or may not have the destination user attached to that node. Only experienced users should configure PNNI manually. 9A656-04 and 9A600 Configuration Guide Non-Modifiable Chassis Slot Number...

  • Page 60: Setting The Pnni Mode

    NOTE display the maximum amount of modifiable bytes that are allowed for that particular setting. 2-32 Section 2.15.1. Upon saving a new NSAP Prefix, all 9A656-04s Section 2.15.4 provide instructions on changing settings 9A656-04 and 9A600 Configuration Guide Section 4.3.1...

  • Page 61: Setting The Pnni Level

    To access the ILMI Configuration screen, perform the following steps: Use the arrow keys to highlight the ILMI CONFIGURATION menu item from the System Configuration Menu screen. Press ENTER. The ILMI Configuration screen, 9A656-04 and 9A600 Configuration Guide The ILMI Configuration Menu Screen through Section 2.16.4...

  • Page 62: Ilmi Configuration Menu Screen Fields

    This field is used to set the maximum value that ILMI will use to assign VPIs to SVPCs. This field has a range from 0 to 4095. The default setting for this field is 4095. 2-34 9A656-04 and 9A600 Configuration Guide...

  • Page 63: Setting The Min Svcc Vci Field

    Enter a value between 0 and 4095 and press ENTER. Use the arrow keys to highlight the SAVE command at the bottom of the screen. Press ENTER, the new maximum VPI value becomes operational. 9A656-04 and 9A600 Configuration Guide The ILMI Configuration Menu Screen Section 2.16.4...

  • Page 64: The Atm Diagnostics Screen

    To enable or diable the power-up ATM Diagnostics, perform the following steps: Use the arrow keys to highlight the POWER UP DIAGS field. Press the SPACE bar to toggle between the options until the desired mode (ENABLED or DISABLED) displays. Any change is automatically saved. 2-36 9A656-04 and 9A600 Configuration Guide...

  • Page 65: Module Configuration Menu Screen

    The port errors screen displays any errors that have occurred on ATM interfaces. This screen specifies on which interface the error occurred, and whether the error occurred on a cell that was received by the interface, or transmitted by the interface. 9A656-04 and 9A600 Configuration Guide Module Configuration Menu Screen Figure 2-21, displays.

  • Page 66: Port Status Screen

    This field reads either UP or DOWN. UP signifies that there is valid physical connectivity on the interface. DOWN signifies there is no valid physical connectivity present on the interface. 2-38 Figure 2-22, displays. Figure 2-22 Port Status Screen 9A656-04 and 9A600 Configuration Guide...
  • Page 67 PNNI 1.0 H - that the PNNI Node ID for this interface is greater than (Higher) the adjacent Node ID. 9A656-04 and 9A600 Configuration Guide Indicates that the 9A656-04 is waiting for ILMI to start on this Indicates that 9A656-04 is waiting for ILMI to stop on this...
  • Page 68 Signalling stack is stopped on this interface. 2-40 Indicates that the stack is waiting for configured Indicates that the interface is waiting for Signalling Indicates that the interface is waiting for Signalling Indicates that Signalling is attempting to start, but is 9A656-04 and 9A600 Configuration Guide...
  • Page 69 To perform the command, use the arrow key to highlight the CLEAR COUNTS command. Press ENTER, the applicable fields are reset. 9A656-04 and 9A600 Configuration Guide Indicates that Signalling is attempting to stop, but is Indicates the interface is waiting for PNNI to start.

  • Page 70: Port Errors Screen

    Module Selection screen 2-42 Figure 2-23, displays. Figure 2-23 Port Errors Screen (00010101) indicates that this interface is port 1 of ANIM 1 9A656-04 and 9A600 Configuration Guide (Figure 2-9).

  • Page 71: Lan Emulation Menu Screen

    To access the LAN Emulation Menu screen, perform the following steps: Use the arrow keys to highlight the LANE menu item on the Configuration Menu screen. Press ENTER. The LAN Emulation Menu screen, 9A656-04 and 9A600 Configuration Guide LAN Emulation Menu Screen Figure 2-24, displays.
  • Page 72 To proceed to the next menu screen, use the arrow keys to highlight the CLIENT menu item on the LAN Emulation Menu screen. Press ENTER, the LAN Emulation Client Menu screen, 2-44 Figure 2-25, displays. 9A656-04 and 9A600 Configuration Guide...

  • Page 73: Lan Emulation Client Menu Screen Fields

    The Admin menu item opens the LAN Emulation Client Administration screen. This screen is used to start, stop, or modify the management LAN Emulation Client. By default, the LEC is started and attempts to connect to the wellknown LECS ATM address. 9A656-04 and 9A600 Configuration Guide 2-45...

  • Page 74: Lan Emulation Client Properties Screen

    field signifies the slot number of the 9A656-04 on which the LEC resides. If the LEC ID field reads “0”, it signifies that this LEC is not a member of an emulated LAN, and is not connected to a LAN Emulation Server. 2-46 Figure 2-26, displays. 9A656-04 and 9A600 Configuration Guide...
  • Page 75 This field displays the current status of the LEC. This field will display “Active” if the LEC is operational or “NotInService” if the LEC has been stopped via management. 9A656-04 and 9A600 Configuration Guide LAN Emulation Client Properties Screen 2-47...
  • Page 76 LEC has with the BUS. This connection is used by the LEC and the BUS to send all broadcast transmissions for address resolution. This connection is also used for unicast and multicast transmissions, when the destination address is unknown. If this LEC is participating in an ELAN, this connection is mandatory. 2-48 9A656-04 and 9A600 Configuration Guide...

  • Page 77: Lan Emulation Client Administration Screen

    Use the arrow keys to highlight the ADMIN menu item from the LAN Emulation Client Menu screen. Press ENTER; the LAN Emulation Client Administration screen, Figure 2-27 LAN Emulation Client Administration Screen 9A656-04 and 9A600 Configuration Guide LAN Emulation Client Administration Screen Figure 2-27, displays.

  • Page 78: Lan Emulation Client Administration Screen Fields

    Instead, the field reads LECS ATM Address. If the LEC is configured automatically, it is not possible to enter the LES ATM Address, as the SmartSwitch 9500 learns the address dynamically from the LECS. 2-50 Section 2.23.2 9A656-04 and 9A600 Configuration Guide...

  • Page 79: Configuring The Lec Automatically

    ELAN the LEC should join, and to which LECS the LEC should connect. Use the arrow keys to highlight the Configure ELAN field. 9A656-04 and 9A600 Configuration Guide LAN Emulation Client Administration Screen are optional, and should only be performed if the user wishes to...

  • Page 80: Configuring The Lec Manually

    Enter the LES ATM Address in the field. Ensure that a valid ATM address is used. Use the arrow keys to highlight the SAVE command at the bottom of the screen and press ENTER. The manually configured LEC will now use the new configuration. 2-52 9A656-04 and 9A600 Configuration Guide...

  • Page 81: Network Tools

    The Network Tools functions are performed using a series of commands. Entering commands in Network Tools involves typing the command to be executed at the Network Tools prompt, adding any desired or required extensions, and pressing ENTER. 9A656-04 and 9A600 Configuration Guide Network Tools Figure 2-28, displays.
  • Page 82 Shows the required command format. It indicates where arguments, if any, must be specified Briefly describes the command and its uses. Lists any additional fields in the appropriate format which may be added to the command. Shows an example of the command. 9A656-04 and 9A600 Configuration Guide...

  • Page 83: Built-In Commands

    You can specify the arp command without options, or with one of the following options: Options: Example: 9A656-04 and 9A600 Configuration Guide arp <options> The arp command provides access to the ARP (Address Resolution Protocol) cache, enabling you to view cache data, delete entries, or add a static route.
  • Page 84 [interface number] [IP address] The defroute command allows the user to view, set or delete the default IP route to a managed device through the specified interface. Not Applicable NetTools-> defroute 2 147.152.42.32 9A656-04 and 9A600 Configuration Guide 051468 051469...
  • Page 85 Syntax: Description: Options: Example: 9A656-04 and 9A600 Configuration Guide netstat [option] The netstat command provides a display of general network statistics for the managed device. The netstat command must be used with one of the two display options. -i Displays status and capability information for each interface...
  • Page 86 ARP caches, route tables, FIB tables, server tables, and interface tables. The number of valid entries in the table will be displayed at the end of the table display. Not Applicable 9A656-04 and 9A600 Configuration Guide 174245...
  • Page 87 # Interface AdminStatus enabled disabled NetTools-> show IP ARP MediaType # Interface 3 (dynamic) 3 (dynamic) traceroute: Syntax: Description: Options: Example: 9A656-04 and 9A600 Configuration Guide OperStatus Forwarding enabled 1500 enabled disabled 1500 disabled PhysicalAddress NetworkAddress 00:00:1d:04:40:5d 123.456.40.1 123.456.40.30 08:00:20:0e:d8:31...

  • Page 88: Special Commands

    Not Applicable NetTools-> soft-reset done The done command enables the user to exit from Network Tools and return to the Main Menu screen. Not Applicable NetTools-> done Connection closed 9A656-04 and 9A600 Configuration Guide 174266 051472...

  • Page 89: The Environmental Module Screen

    Displays the hardware revision of the environmental module. SN (Read-only) Displays the serial number of the environmental module. MAC Address (Read-only) Displays the physical address of the environmental module. 9A656-04 and 9A600 Configuration Guide The Environmental Module Screen Figure 2-29, displays. 2-61...
  • Page 90 ENABLED and DISABLED. To change the setting of the COM1 port refer to Section 2.25.2. Application (Read-only) The Application field for the COM1 port may not be changed. COM1 port is reserved for Local Management use only. 2-62 Section 2.25.1. 9A656-04 and 9A600 Configuration Guide...

  • Page 91: Setting The Fan Speeds

    Press the SPACE bar to step through the available options until the desired configuration displays. Use the arrow keys to highlight the SAVE command at the bottom of the screen and press ENTER. The fans begin operating at the new setting. 9A656-04 and 9A600 Configuration Guide The Environmental Module Screen Section 2.25.4.

  • Page 92: Enabling/Disabling Com1 And Com2

    9600, and 19,200. Use the Space Bar to toggle to the desired baud rate. Use the arrow keys to highlight the SAVE command at the bottom of the screen. Press ENTER, the changes are saved to memory. 2-64 9A656-04 and 9A600 Configuration Guide...

  • Page 93: Downloading A New Image Into Flash Memory

    The SmartSwitch 9500 has a default traffic descriptor defined in row 10. This will always be present on the system unless it is manually deleted by the user. In this example, the default traffic descriptor will be used. 9A656-04 and 9A600 Configuration Guide Creating a PVC 2-65...

  • Page 94: Adjusting Ilmi Parameters For Pvc Creation

    In this example, the ILMI Configuration screen is used to set the following parameters: • The MIN SVCC VCI field is set to 100 • The MAX SVCC VPI field is set to 0 2-66 for more information on ILMI. Figure 2-30 ILMI Configuration Screen 9A656-04 and 9A600 Configuration Guide...

  • Page 95: Setting The Instance Of The First Interface

    ANIM 1 of the 9A656-04 installed in slot 7). The VPI value will be 2, and the VCI value will be 50. 2.26.3 Setting the Instance of the First Interface This section provides instructions on setting the Instance of the interfaces. Refer to Figure 2-31. Figure 2-31 Setting the Instance 9A656-04 and 9A600 Configuration Guide 2-67...
  • Page 96 After these steps have been completed for the first interface, the same configuration must be performed for the second interface. In this case, the SNMP command line would be: snmpset -h 134.141.87.75 1.3.6.1.2.1.37.1.7.1.13.70102.2.50 Integer 5 2-68 9A656-04 and 9A600 Configuration Guide...

  • Page 97: Setting The Traffic Descriptor For The Receive Side Of The Interfaces

    70101, and it has been assigned a VPI/VCI pair of 2.50. This also displays the traffic descriptor value that has been assigned (10). Confirmation that the selected interface and VPI/VCI pair has been assigned to the traffic descriptor value 10. 9A656-04 and 9A600 Configuration Guide 2-69...

  • Page 98: Setting The Traffic Descriptor For The Transmit Side Of The Interfaces

    first interface. The definitions for the callouts are as follows: Displays the name of the MIB command used to perform this procedure (atmVclTransmitTrafficDescrIndex) and the OID string the SNMP application is using to access this information (1.3.6.1.2.1.37.1.7.1.7). 2-70 9A656-04 and 9A600 Configuration Guide...

  • Page 99: Setting The Vcl Status To Active

    -h 134.141.87.75 1.3.6.1.2.1.37.1.7.1.7.70102.2.50 Integer 10 2.26.6 Setting the VCL Status to Active This section provides instructions on setting the VCL Status to active. Refer to Figure 2-34. Figure 2-34 Setting the VCL Status to Active 9A656-04 and 9A600 Configuration Guide 2-71...
  • Page 100 After these steps have been completed for the first interface, the same configuration must be performed for the second interface. In this case, the SNMP command line would be: snmpset -h 134.141.87.75 1.3.6.1.2.1.37.1.7.1.13.70102.2.50 Integer 1 2-72 9A656-04 and 9A600 Configuration Guide...

  • Page 101: Getting The Cross-Connect Identifier (Ccid)

    CCID value. In this example, the CCID has been assigned a value of 3596. This is the CCID to which the PVC will be assigned. 9A656-04 and 9A600 Configuration Guide Figure 2-35 Getting the CCID Creating a PVC...

  • Page 102: Activating The Pvc

    The first interface, and it’s VPI/VCI pair, followed by the second interface, and its VPI/VCI pair (70101.2.50.70102.2.50). This also displays that the PVC has been set to createAndGo. Confirmation that the PVC has been set to createAndGo. 2-74 9A656-04 and 9A600 Configuration Guide...
  • Page 103 (atmVcCrossConnectRowStatus) and the OID string the SNMP application is using to access this information (1.3.6.1.2.1.37.1.11.1.13). The Instance field displays that the PVC has been created on CCID 3596. The Value field displays that the PVC is currently active. 9A656-04 and 9A600 Configuration Guide 2-75...
  • Page 104 Chapter 2: Basic System Configuration 2-76 9A656-04 and 9A600 Configuration Guide...

  • Page 105: Chapter 3 Ilmi 4.0 And The Smartswitch 9500 System

    This document may be downloaded from the following URL: www.atmforum.com All references to the CTM backplane or CTM interfaces apply ONLY to the 9A656-04 ATM SmartSwitch module, as the 9A600 does not connect to the CTM backplane. ILMI AUTOCONFIGURATION EXAMPLES Figure 3-1 provides five examples that display how each 9A656-04 in the SmartSwitch 9500...
  • Page 106 The In-Band Management LEC will respond to management requests from any NOTE interface on the system. The NMS described in this definition is only an example of how this function can work. Individual 9A656-04 or 9A600 Module ANIM-21/3 3 OC-3 Interfaces...
  • Page 107 In this example, the third party ATM switch has been autoconfigured to be the User side of the connection, as it has the lower system ID. The 9A656-04 is maintaining the Network side of the connection. 9A656-04 and 9A600 Configuration Guide...
  • Page 108 The (H) and (L) in Example 4 of SmartSwitch 9500 is (in a bitwise comparison) greater than(Higher) or less than (Lower) than the adjacent PNNI Node. Figure 3-1 indicated whether the node ID of each 9A656-04 and 9A600 Configuration Guide Section 2.15...

  • Page 109: Port Status Screen

    Section 1.4 provides a breakdown of the port numbering scheme. 9A656-04 and 9A600 Configuration Guide Figure 3-2 describes in detail all the fields of the Port Status screen. Figure 3-2 Port Status Screen Example...
  • Page 110 It could mean that the port requested a new stack, and so the old stack was torn down. This can be caused by the neighbor sending a cold start trap, change stack type requests, etc. 9A656-04 and 9A600 Configuration Guide...

  • Page 111: Ilmi Configuration Screen

    The main purpose of the ILMI configuration screen is to limit the range of VPI/VCI pairs for SVC connections. In the default setting, there are no VPI/VCI pairs reserved for PVCs. Refer Figure 3-3. 9A656-04 and 9A600 Configuration Guide Table 3-1 provides the default settings ILMI uses when Table 3-2 displays the available range of VCI/VPI pairs describes how to use the ILMI Configuration screen to...
  • Page 112 VCI 33-16K VPI 0-4095 VCI Range Figure 3-3 Default ILMI Settings 3-3. By default, the 9A656-04 is an SVC only switch. This 9A656-04 and 9A600 Configuration Guide Reserved by the ATM Forum VCI Values 33-16K VPI Values 0-4095 Available for Use by...
  • Page 113 ILMI Configuration screen may be used to change the SmartSwitch 9500 from the default settings. The settings entered in configuration shown in Figure 9A656-04 and 9A600 Configuration Guide 3-5. ILMI Configuration Screen Figure 3-4 result in the...
  • Page 114 VPI 5-4095 33-199 0-4095 VCI 200-16k, VPI 4 VCI 200-16k, VPI 0-3 VCI Range Min SVCC VCI=200 9A656-04 and 9A600 Configuration Guide Reserved by the ATM Forum VCI Values 33-16K VPI Values 5-4095 Available for Use by PVCs Only VCI Values 33-199...

  • Page 115: Chapter 4 Signalling And Routing

    All references to the CTM backplane or CTM interfaces apply ONLY to the 9A656-04 ATM SmartSwitch module, as the 9A600 does not connect to the CTM backplane. This chapter is divided into the following three subsections: •...

  • Page 116: Signalling Overview

    AToM MIB. In autoconfiguration, the two connected devices negotiate to the highest supported UNI or NNI version. The necessary parameters are set up, and the Signalling stack becomes operational. To configure the stack manually, refer to the Section 4.2.3 Section 4.2.4. 9A656-04 and 9A600 Configuration Guide...

  • Page 117: Setting Types

    (ILMI 4.0), or the NVRAM of the entire 9A656-04 is cleared. Figure 4-1 provides an example of using a NMS to configure an interface to use a specific Signalling stack. Figure 4-1 Setting the UNI Version Via the AToM MIB Example 9A656-04 and 9A600 Configuration Guide...
  • Page 118 UNI 3.0 only, port 2 UNI 3.1 only, and port 3 UNI 4.0 only. It also shows that ports 1 and 2 of ANIM 2 are using the default setting of autoConfig (ILMI 4.0) for their Signalling stack. 9A656-04 and 9A600 Configuration Guide...

  • Page 119: Setting Sides

    Signalling side back to autoconfig (ILMI 4.0), or the NVRAM of the entire 9A656-04 is cleared. Figure 4-2 provides an example of using a NMS to configure an interface to use a specific Signalling stack. Figure 4-2 Setting the UNI Side Via the AToM MIB Example 9A656-04 and 9A600 Configuration Guide Signalling Overview...
  • Page 120 2 and 3 of ANIM 1 of the 9A656-04 installed in slot 4 have been configured to be on the user and network side respectively. Port 1 has kept the default setting of “other”, which can indicate an ILMI 4.0, PNNI 1.0, or BICI 2.0 stack. 9A656-04 and 9A600 Configuration Guide...

  • Page 121: Routing Overview

    PNNI for its protocol stack, and ILMI is operating, that interface will automatically use PNNI for its Signalling stack. Individual interfaces can also be configured to use PNNI only, as described in 9A656-04 and 9A600 Configuration Guide Routing Overview Section...

  • Page 122: Peer Groups

    The 9A656-04 can, however, be a border node interconnecting two or more peer groups. The next firmware revision will allow the 9A656-04 to be a peer group leader. NOTE 9A656-04 and 9A600 Configuration Guide...

  • Page 123: Crankback

    In the event that no switch can meet the QoS requirements, the connection will be refused. PNNI attempts to limit the amount of crankback on the network by using Generic Call Admission Control (GCAC), as described in 9A656-04 and 9A600 Configuration Guide Figure 4-3.

  • Page 124: Gcac

    The 9A656-04 supports the following UNI Signalling specifications for IISP connections: • UNI 3.0 • UNI 3.1 • UNI 4.0 4.4.2 UNI Sides The 9A656-04 supports both network and user side UNI Signalling for IISP connections. 4-10 9A656-04 and 9A600 Configuration Guide...

  • Page 125: Configuring Iisp

    • Signalling Configuration • Step 1: Setting the Signalling Stack Type • Step 2: Setting the Signalling Side • Step 3: Create and Configure a Reachable Address 9A656-04 and 9A600 Configuration Guide (Section 4.5.1.1) (Section 4.5.1.2) (Section 4.6) Configuring IISP...

  • Page 126: Signalling Configuration

    Displays the name of the MIB command used to perform this procedure (atmIntfConfigType) and the OID string the SNMP application is using to access this information (1.3.6.1.2.1.37.14.1.14.1.1). 4-12 Figure 4-4. Figure 4-4 Setting the Signalling Stack 9A656-04 and 9A600 Configuration Guide...
  • Page 127 The interface on the adjacent ATM switch must be set to the same IISP type and opposite side for IISP to function properly. CAUTION Displays that the setting of the Signalling stack for this interface was successful. 9A656-04 and 9A600 Configuration Guide Configuring IISP 4-13...

  • Page 128: Step 2: Set The Iisp Side

    Signalling side. The definitions for the callouts are as follows: This section of the screen displays the name of the MIB command used to perform this procedure (atmIntfConfigSide) and the OID string the SNMP application is using to access this information (1.3.6.1.2.1.37.14.1.14.1.3). 4-14 9A656-04 and 9A600 Configuration Guide...
  • Page 129 “user”, indicating the other switch must be set to “network”. Displays that the setting of the Signalling side for this interface was successful. Once these steps have been completed, proceed to address (static route). 9A656-04 and 9A600 Configuration Guide Configuring IISP Section 4.6 to configure the reachable...

  • Page 130: Creating And Configuring A Reachable Address (Static Route)

    Step 2: Associate the Reachable Address with its Advertising Node ID • Step 3: Associate the Reachable Address with a Port ID • Step 4: Associate the Reachable Address with an Interface 4-16 (Section 4.6.1) (Section (Section 4.6.3) (Section 4.6.4) 9A656-04 and 9A600 Configuration Guide 4.6.2)

  • Page 131: Step 1: Create A Row In The Pnnirouteaddrtable

    The definitions for the callouts are as follows: Displays the name of the MIB command used to perform this procedure (pnniRouteAddrRowStatus) and the OID string the SNMP application is using to access this information (1.3.6.1.4.1.353.5.4.1.1.19.4.1.17). 9A656-04 and 9A600 Configuration Guide 4-17...
  • Page 132 This section of the screen displays the table of entries in the PNNI Route Address table. Once the example in this section is “active”, the appropriate instance will be displayed in this section. SNMP confirmation that the instance has been created and is now in the create stage. 4-18 9A656-04 and 9A600 Configuration Guide...

  • Page 133: Step 2: Associate The Reachable Address With Its Advertising Node Id

    This field is used to enter the ATM address of that was entered in the RowStatus screen shown back in Figure 4-6 (7000001.71.0.121.0.0.0.0.0.0.0.0.0.0.0.160.62.0.0.1.152.2). The address directly to the right of this field displays the hexadecimal value of ATM address of the 9A656-04 installed in slot 7 of the chassis. 9A656-04 and 9A600 Configuration Guide 4-19...
  • Page 134 This field displays that the instance has been successfully set, and the Node ID screen updates to show that the instance has been created. See the highlighted section of the screen in Figure 4-8. Figure 4-8 Updated Node ID screen 4-20 9A656-04 and 9A600 Configuration Guide...

  • Page 135: Step 3: Associate The Reachable Address With A Port Id

    “0”, which indicates that an interface has not yet been assigned to the configured ATM address and that the “0” represents the Node ID. Figure 4-10 displays the screen after an interface has been assigned to this instance. 9A656-04 and 9A600 Configuration Guide 4-21...
  • Page 136 (70101, or port 1 of ANIM 1 of the 9A656-04 installed in slot 7 of the chassis). Displays that the setting of this interface to the instance was successful. 4-22 9A656-04 and 9A600 Configuration Guide...

  • Page 137: Step 4: Associate The Reachable Address With An Interface

    This section of the screen displays the name of the MIB command used to perform this procedure (pnniRouteAddrAdvertisePortId) and the OID string the SNMP application is using to access this information (1.3.6.1.4.1.353.5.4.1.1.19.4.1.6). 9A656-04 and 9A600 Configuration Guide 4-23...
  • Page 138 Ensure that the same interface, in this example 70101, is set for both the Port ID and the IFIndex. CAUTION Displays that the setting of this interface to the instance was successful. The static route is now configured. 4-24 9A656-04 and 9A600 Configuration Guide...

  • Page 139: Appendix A Acronyms

    ASCII - Asynchronous Transfer Mode ATM - Bridged Ethernet BE - Bit Error Ratio (Rate) BER - Broadband Inter-Carrier Interface B-ICI - Broadband Integrated Services Digital Network B-ISDN - Boot Protocol BOOTP - 9A656-04 and 9A600 Configuration Guide ACRONYMS APPENDIX A...
  • Page 140 Digital Cross Connect, generic DACS or Direct Connect Card, data interface module DCC - Download Flash DF - Digital Signaling 0 DS-0 - Digital Signaling 1 DS-1 - Digital Signaling 3 DS-3 - Data Terminal Equipment DTE - Delay Variation Tolerance DVT - 9A656-04 and 9A600 Configuration Guide...
  • Page 141 First In First Out FIFO - File Transfer Protocol FTP - Gigabits per second Gbps - Generic Call Admission Control GCAC - Generic Cell Rate Algorithm GCRA - Generic Flow Control GFC - Header Error Check HEC - 9A656-04 and 9A600 Configuration Guide...
  • Page 142 LECS - LAN Emulation Configuration Server Emulated LAN LECSELAN - LANE Server LES - LANE Server Emulated LAN LESELAN - Logical IP Subnetwork LIS - Logical Link Control LLC - Local Management Interface LMI - 9A656-04 and 9A600 Configuration Guide...
  • Page 143 Operations, Administration, Maintenance and Provisioning OAM&P - Optical Carrier 1 OC-1 - Optical Carrier n (where "n" is an integer) OC-N - Open Data-link Interface ODI - Out of Band OOB - Open Systems Interconnection OSI - 9A656-04 and 9A600 Configuration Guide...
  • Page 144 Raw Cell Received RCR - Receive Deactivated RD - Request for Comment RFC - Receive Queue Underrun RQU - Recommended Standard defined by Electronic Industries Association RS-# - Real Time - Variable Bit Rate RT-VBR - 9A656-04 and 9A600 Configuration Guide...
  • Page 145 Transmission System 3 T-3 - Transparent Asynchronous Transmitter/Receiver Interface TAXI - Transmission Control Protocol TCP - Traffic Descriptor TD - Time-Division Multiplexing TDM - Trivial File Transfer Protocol TFTP - Type, Length and Value TLV - 9A656-04 and 9A600 Configuration Guide...
  • Page 146 Virtual Channel Link VCL - Virtual LAN VLAN - Virtual Path VP - Virtual Path Connection VPC - Virtual Path Identifier VPI - Virtual Private Network VPN - Virtual Tributary VT - Wide Area Network WAN - 9A656-04 and 9A600 Configuration Guide...

  • Page 147: Appendix B Default Settings

    Signalling stack required by the device to which the interface is attached. Refer to Chapter 3 for information on ILMI. Refer to Chapter 4 for instructions on hard setting the Signalling stacks for individual interfaces. 9A656-04 and 9A600 Configuration Guide...

  • Page 148: Ilmi Settings

    The SmartSwitch 9500 is set to be in Clock Recovery Mode, which means that all clocking will be recovered from the received signals. B.1.9 Maximum Number of Connections The SmartSwitch 9500 is configured by default to allow a maximum of 128k connections per 9A656-04. 9A656-04 and 9A600 Configuration Guide...

  • Page 149: Appendix C Supported Mibs

    1.3.6.1.2.1. It also can be expressed as iso.org.dod.internet.mgmt.mib (see For the authoritative reference on the concepts described in this section, refer to NOTE RFCs 1901 through 1908. 9A656-04 and 9A600 Configuration Guide SUPPORTED MIBS Figure C-1). APPENDIX C Figure C-1).
  • Page 150 Appendix C: Supported MIBs CCITT directory root internet experimental mgmt MIB2 Figure C-1 Internet MIB Hierarchy 9A656-04 and 9A600 Configuration Guide joint ISO/CCITT private Label from the root to this point is 1.3.6.1.2.1...

  • Page 151: Smartswitch 9500 Mib Hierarchy

    AToM MIB AToM MIB objects private AToM MIB2 enterprise Supplemental atmForum cabletron ctFlash .4.1.5.10 PNNI ILMI SPVC 5.4.1.1 .5.5 ctNetwork .4.1.3 ctronMib2 .4.3.3 ctPIC .4.1.5.9 nwRouter .4.2.2.2 sfcs .4.1.2.11.1.1 Figure C-2 Supported MIBs Hierarchy 9A656-04 and 9A600 Configuration Guide...
  • Page 152 Table C-2 Non-Distributed MIB2 (OID String: 1.3.6.1.2.1) Branch Address Translation Group IP Group ICMP Group Udp Group Snmp Group Branch.Leaf .1.1-7 .2.1 .2.2.1.1-22 .10.33.1 .10.33.2.1.1-6 Branch.Leaf .3.1.1.1-3 .4.1-19 .4.21.1-13 .4.22.1.1-4 .4.23 .4.24.1 .4.24.2.1.1-15 .5.1-26 .7.1-4 .7.5.1.1-2 .11.1-6 .11.8-22 .11.24-30 9A656-04 and 9A600 Configuration Guide...
  • Page 153 Table C-4 Non-Distributed AToM MIB (OID String: 1.3.6.1.2.1.37.1) Branch atmTrafdesc-ParmTable (PVC and SVC ) Table C-5 Distributed Supplemental AToM MIB (OID String 1.3.6.1.2.1.37.14.1) Branch atmSvcVpCrossConnectTable atmSvcVcCrossConnectTable atmSigStatTable atmIlmiSrvcregtable atmVplStatTable 9A656-04 and 9A600 Configuration Guide SmartSwitch 9500 MIB Hierarchy Branch.Leaf .2.1.1-8 .2.1.11-12 .4.1.1-2 .6.1.1-10 .7.1.1-7 .7.1.12-15 .9.1.1-11 .11.1.1-13 Branch.Leaf...
  • Page 154 Branch.Leaf .11.1.1 .11.1.3 .11.1.5 .11.1.6 .14.1.1-24 .15.1.1-6 .16.1.1-2 Branch.Leaf .1.1 .1.2 .1.4 .2.4-11 Branch.Leaf .1.19. all leaves Branch.Leaf .4.1.1.7.1.1-10 .4.1.1.7.2.1.1.1-8 .4.1.1.7.2.2.1.1-9 .4.1.1.7.5.1-5 .4.1.1.8.1.1-12 .4.1.1.8.2.1.1.1-13 .4.1.1.9.1.1-9 .4.1.1.9.2.1.1.1-9 .4.1.1.9.3.1.1.1-6 9A656-04 and 9A600 Configuration Guide...
  • Page 155 Table C-9 Non-Distributed Cabletron MIBs Branch communityEntry boardPowerSlotStatus boardPowerSlotEntry boardEnvSlotEntry contType contLogical 9A656-04 and 9A600 Configuration Guide SmartSwitch 9500 MIB Hierarchy Branch.Leaf .4.1.1.9.3.2.1.1-2 .4.1.1.9.5.1-3 .4.1.1.9.6.1.1.1-3 .4.1.1.10.1 .4.1.2.10.1.1. .4.1.2.10.1.3-5. .4.1.2.11.1.1.1.1-3 . 4.1.2.11.1.1.2.1-4 .4.1.2.11.1.1.3.1. .4.1.2.11.1.1.3.2. .4.1.2.11.1.1.3.3.1.1.1-23.
  • Page 156 Table C-12 Non-Distributed ctFlash MIB (OID String: 1.3.6.1.4.1.52.4.1.5.10) Branch ctFlash Table C-13 Non-Distributed nwRouter MIB (OID String: 1.3.6.1.4.1.52.4.2.2.2) Branch nwRtrMibs nwRtrHighLevelView Branch.Leaf .4.1.1.9.3.1.1.1-6 .4.1.1.9.3.2.1.1-2 .4.1.1.9.5.1-3 .4.1.1.12.1.1-2 Branch.Leaf .1.1.1 Branch.Leaf .1.1-3 .1.5 .1.8 Branch.Leaf .1-3 Branch.Leaf .1.1-2 .2.1 .2.3-4 9A656-04 and 9A600 Configuration Guide...
  • Page 157 Table C-15 Non-Distributed ctron Mib2 MIB (OID String: 1.3.6.1.4.1.52.4.3.3) Branch ctlf ctlfport Table C-16 Distributed and Non-Distributed ctron Mib2 MIB (OID String: 1.3.6.1.4.1.52.4.1.5.7.1.1.1) Branch ctTrap 9A656-04 and 9A600 Configuration Guide SmartSwitch 9500 MIB Hierarchy Branch.Leaf .3.1.1 .3.1.2.1-2 .3.1.2.6.3.1.1.1-7 .3.1.2.10.1.1-3 Branch.Leaf .1.1-3...
  • Page 158 Appendix C: Supported MIBs C-10 9A656-04 and 9A600 Configuration Guide...

This manual is also suitable for:

9a656-04

Table of Contents
