3.3

ILMI CONFIGURATION SCREEN

Local management of the SmartSwitch 9500 allows the user to specify minimum and
maximum values for VCI and VPIs for all SVCs and SPVCs that the SmartSwitch 9500 will
use while establishing connections.
first connected to the ATM network.
that ILMI may be configured to allow for requested connections.
Section 2.16
NOTE
change the settings from their default values.
Table 3-1 Default Minimum and Maximum VCI and VPI Values for SVCs and SVPCs
Minimum VCI for SVCs
(MIN SVCC VCI field)
Maximum VPI for SVCs
(MAX SVCC VPI field)
Maximum VPI for VPCs
(MAX SVPC VPI field)
Table 3-2 Minimum and Maximum VCI and VPI Ranges
Type
VCI for SVCs
Maximum VPI for SVCs
Maximum VPI for VPCs
The main purpose of the ILMI configuration screen is to limit the range of VPI/VCI pairs for
SVC connections. In the default setting, there are no VPI/VCI pairs reserved for PVCs. Refer
to Figure 3-3.
9A656-04/9A686-04 Configuration Guide
Table 3-1
Table 3-2
in Chapter 2 describes how to use the ILMI Configuration screen to
provides the default settings ILMI uses when
displays the available range of VCI/VPI pairs
33
4095
4095
Minimum Value Maximum Value
33 16k
0 4095
0 4095
ILMI Configuration Screen
Page 3-7
