Chapter 2: System Configuration
10. Press ENTER. If all the values entered in the applicable fields are valid, the destination end
of the SPVP is created.

2.25.3 Creating the Destination End of a SPVC

To create the destination end of a SPVC, perform the following steps:
1. Use the arrow keys to highlight the INTERFACE field.
2. Enter a valid interface number. For example,
9A686-04 installed in slot 7 of the SmartSwitch 9500. Therefore, a valid source interface
value would be 70202 (port 2 of ANIM 2).
In steps 3
NOTE
current ILMI settings, and the amount of the VPIs/VCIs currently being used by
SVCs. Refer to
The device that will support the source end of this SPVC MUST have the same
!
destination VPI/VCI values assigned as those entered in steps
CAUTION
source device does not have the same destination VPI/VCI values assigned, the
SPVC will NOT be created.
If the device that will support the source end of this SPVC is another 9A686-04,
refer to Section 2.24
3. Use the arrow keys to highlight the VPI field.
4. Enter a valid VPI value.
5. Use the arrow keys to highlight the VCI field.
6. Enter a valid VCI value.
7. Use the arrow keys to highlight the ATM ADDRESS field.
8. Enter a unique, 40 bit ATM address.
9. Use the arrow keys to highlight the TOGGLE PERSISTENCE command at the bottom
of the screen.
Setting the ATOM persistence to "ON" signifies that in the event that the 9A686-04
!
module or SmartSwitch 9500 chassis is reset, this SPVC will still exist after boot up.
CAUTION
Setting the ATOM persistence to "OFF" signifies that if the module or chassis is
reset, this SPVC will be lost upon boot up.
2-56
and 6, the available range for the applicable fields depends on the
Section 2.17 and
for instructions on creating the source end of the SPVC.
Figure 2-26 displays a screen shot of a
Chapter 3 for more information ILMI.
9A656-04/9A686-04 Configuration Guide
3 and 6. If the
