- Page 1 SmartSwitch 9000 9H423-28 Local Management Appendix 9032060-01...
-
Page 3: Modifying Fields And User Privileges
9H423-28 Module Specific Information Introduction This appendix contains local management information that is specific to the 9H423-28 Ethernet Module. The 9H423-28 Ethernet Module is a 28-port switching module with: • 24 10Mb front panel Ethernet ports (2 RJ71 Telco) • 4 100Mb front panel Ethernet ports (2 RJ45, 1 FEPIM, & 1 MMF SC) •... -
Page 4: Module Interface Codes
9H423-28 Module Specific Information Module Interface Codes The 9H423-28 Module has 33 interfaces. Table 1 lists the identifying number, name, and description of each interface. Interface Interface Number ENET10 ENET11 ENET12 ENET13 ENET14 ENET15 ENET16 ENET17 ENET18 Table 1. 9H423-28 Module Interface Codes Name Description SMB1... - Page 5 Table 1. 9H423-28 Module Interface Codes (Continued) Interface Interface Number Name ENET19 ENET20 ENET21 ENET22 ENET23 ENET24 ENET25 ENET26 ENET27 ENET28 Use the numbers listed in Table 1 to configure the module’s default interface (see the General Configuration Screen). 9H423-28 Module Specific Information Interface Description Ethernet Front Panel Port 19...
-
Page 6: Port Configuration Screen
9H423-28 Module Specific Information Port Configuration Screen The 9H423-28 Port Configuration Screen (Figure 1), allows you to configure the Desired Operational Mode and the Advertising Ability of the module. Module Name: 9H423-28 Slot Number: 5 Port Type Link Status Current Operation Mode Buffer Utilization Desired Operation Mode Advertised Ability... - Page 7 9H423-28 Module Specific Information Port Configuration Screen Fields The following information briefly explains each Port Configuration Screen field. Port # Displays the port number of the current 100 Mb Ethernet port. Port Type Displays one of the following values: • AUI •...
- Page 8 9H423-28 Module Specific Information Desired Operational Mode (Toggle) Allows you to specify how you want the port to communicate with a device. If you specify Auto-Negotiation, the port and the device automatically synchronize communication. Valid modes are: • Auto-Negotiation • 10Base-T •...
-
Page 9: Port Statistics Screen
Port Statistics Screen The 9H423-28 Port Statistics Screen (Figure 2), displays information and statistics about the module’s Ethernet ports. Module Name: 9H423-28 Slot Number: 5 PACKETS: TOTAL ERRORS: COLLISIONS: CRC/ALIGNMENT ERRORS: UNDERSIZE PACKETS: OVERSIZE PACKETS: FRAGMENTS: JABBERS: BROADCASTS: MULTICASTS: PORT #:[ 1] SmartSwitch 9000 Local Management Port Statistics... - Page 10 9H423-28 Module Specific Information Port Statistics Screen Fields The following information briefly explains each Port Statistics Screen field. PORT # Indicates the current port for which statistics are displayed. OCTETS Displays the number of octets transmitted and received. PACKETS Displays the number of packets transmitted and received. TOTAL ERRORS Displays the total number of errors on this port.
- Page 11 MULTICASTS Displays the number of multicasts received. LINK STATUS Indicates whether there is a physical connection from this port to another device. One of the following values appears: • Link - There is a link signal present; there is a valid physical connection from this port to another device.
- Page 12 9H423-28 Module Specific Information PORT # (Modifiable) Selects the port for which statistics are to be displayed. Displaying Statistics for Another Port To display statistics for another port: 1. Use the arrow keys to highlight the Port # field at the bottom of the screen. 2.
