Admin State (Read-Only)
Displays the current status of the LEC. This field will display "Running" if the LEC is
operational or "NotInService" if the LEC has been stopped via management.
LANE Version (Read-Only)
Displays the current version of LAN Emulation being used. This field reads [1.0] only.
LEC ATM ADDR (Read-Only)
Displays the ATM Address of the LEC.
LECS ATM ADDR (Read-Only)
Displays the ATM address of the LAN Emulation Configuration Server. If this LEC was
configured manually, this field can be empty.
LES ATM ADDR (Read-Only)
Displays the ATM Address of the LAN Emulation Server to which the LEC is connected.
BUS ATM ADDR (Read-Only)
Displays the ATM address of the Broadcast or Unknown Server to which the LEC is
connected.
LECS Configuration Direct VCC (Read-Only)
Displays the VPI and VCI of the Configuration Direct Virtual Channel Connection (VCC) that
the LEC has with the LECS. This connection is used to obtain LAN Emulation configuration
parameters, and is also used by the LEC to learn the address of the LES.
In many ELAN implementations, the LECS Configuration Direct VCC is only used
NOTE
temporarily, and the VCC may time out.
LES Control Direct VCC (Read-Only)
Displays the VPI and VCI of the Control Direct Virtual Channel Connection (VCC) that the
LEC has with the LES. This connection is used by the LES and the LEC to distribute control
traffic to all LECs. If this LEC is participating in an ELAN, this connection is mandatory.
LES Control Distribute VCC (Read-Only)
Displays the VPI and VCI of the Control Distribute Virtual Channel Connection (VCC) that
the LEC has with the LES. This optional connection is used by the LES to distribute control
traffic to all LECs.
