Creating and Configuring a Reachable Address (Static Route)

4.6.1 Step 1: Create a Row in the pnniRouteAddrTable

This section provides an example of how to create a new row in the PNNI Route Address
Table. Refer to Figure 4-6.
A
B
C
D
Figure 4-6 Creating an Entry in the pnniRouteAddr Table
Figure 4-6 contains 4 callouts that display status information, and the configuration fields
necessary to create an entry in the pnniRouteAddr table. The definitions for the callouts are as
follows:
A
Displays the name of the MIB command used to perform this procedure
(pnniRouteAddrRowStatus) and the OID string the SNMP application is using to access this
information (1.3.6.1.4.1.353.5.4.1.1.19.4.1.17).
