Chapter 27 Cisco IOS IPS
Disable Button
Disable All Button
Interface Name
IP
Inbound IPS/Outbound IPS
VFR Status
OL-4015-12
Click to disable Cisco IOS IPS on the specified interface. A context menu shows
you the traffic directions on which Cisco IOS IPS has been applied, and you can
choose the direction on which you want to disable Cisco IOS IPS. If you disable
Cisco IOS IPS on an interface to which it has been applied, Cisco SDM
dissociates any Cisco IOS IPS rules from that interface.
Click to disable Cisco IOS IPS on all interfaces on which it has been enabled. If
you disable Cisco IOS IPS on an interface to which it has been applied, Cisco
SDM dissociates any Cisco IOS IPS rules from that interface.
The name of the interface. For example: Serial0/0, or FE0/1.
This column can contain the following types of IP addresses:
Configured IP address of the interface.
•
DHCP client—The interface receives an IP address from a Dynamic Host
•
Configuration Protocol (DHCP) server.
Negotiated—The interface receives an IP address through negotiation with
•
the remote device.
Unnumbered—The router will use one of a pool of IP addresses supplied by
•
your service provider for your router and for the devices on your LAN.
Not applicable—The interface type cannot be assigned an IP address.
•
• Enabled—Cisco IOS IPS is enabled for this traffic direction.
Disabled—Cisco IOS IPS is disabled for this traffic direction.
•
Virtual Fragment Reassembly (VFR) status. The possible values are:
Cisco Router and Security Device Manager 2.5 User's Guide
Edit IPS
27-11
