Chapter 29 Quality of Service
QoS Wizard
Interface Selection
Table 29-1 Interface Selection
Element
Details
OL-4015-12
This window summarizes the information that you will be providing as you
complete the QoS Policy wizard.
Click the Next button to begin configuring a
Choose the interface on which you want to configure the
window. This window lists WAN interfaces, and interfaces which do not have a
configured outbound QoS policy. VPN interfaces are included in the list, but
interfaces used for Easy VPN clients, and interfaces with an existing QoS policy
are not included.
If the router Cisco IOS image release is 12.4(11)T or later, virtual template tunnel
interfaces may appear in this list. If you choose a VTI interface, you will be able
to configure shaping and queuing parameters.
Field Reference
Description
To view configuration details about the chosen interface, click
Details. The window displays the interface's IP address and subnet
mask, names of access rules and policies applied to the interface,
and connections the interface is used for.
Cisco Router and Security Device Manager 2.5 User's Guide
Creating a QoS Policy
QoS policy.
QoS policy in this
29-3
