Chapter 29 Quality of Service

Editing QoS Policies

Match DSCP: ef
Queuing: LLQ
Bandwidth Percentage: 33
----------------------------------------------------------------------
Class Name: SDM-Signalling-1
----------------------------------------------------------------------
Enabled: Yes
Match DSCP: cs3,af31
Queuing: CBWFQ
Bandwidth Percentage: 5
----------------------------------------------------------------------
Class Name: SDM-Routing-1
----------------------------------------------------------------------
Enabled: Yes
Match DSCP: cs6
Queuing: CBWFQ
Bandwidth Percentage: 5
----------------------------------------------------------------------
Class Name: class-default
----------------------------------------------------------------------
Enabled: Yes
Match Protocols:
Queuing: Fair Queue
Random Detect: Yes
----------------------------------------------------------------------
Class Name: SDM-Streaming-Video-1
----------------------------------------------------------------------
Enabled: No
Match DSCP: cs4
Editing QoS Policies
Complete these steps to edit a QoS policy:
If you want to review the Cisco IOS CLI commands that you send to the router
Step 1
when you complete the configuration, go to the Cisco SDM toolbar, and click Edit
> Preferences > Preview commands before delivering to router. The preview
screen allows you to cancel the configuration if you want to.
Cisco Router and Security Device Manager 2.5 User's Guide
29-9
OL-4015-12
