VPN Status

SSL VPN Components

System Resources
Number of Connected Users
Tabbed Area
Cisco Router and Security Device Manager 2.5 User's Guide
42-18
Clear button—Select a row in the table and click Clear to clear the IKE SA
•
connection.
Clicking the VPN Status button in the monitoring window causes the router to
begin monitoring SSL VPN activity. This window displays the data gathered for
all SSL VPN contexts configured on the router.
By default, this data is refreshed every 10 seconds. If 10 seconds is too short an
interval for you to view data before the next refresh, you can select an auto-refresh
interval of Real-time data every minute.
Choose a context in the SSL VPN tree to view data for that context and data for
the users who are configured for the context.
The percentage of CPU and memory resources that SSL VPN traffic is using
across all contexts is shown in this area.
This graph shows the number of active users over time. The peak number of active
users since monitoring began is displayed at the top of the graph area. The time
that monitoring began is shown in the lower left-hand corner of the graph, and the
current time is shown centered under the graph.
This area of the window displays gathered statistics in a series of tabs for easier
viewing.
Click any of the links below for a description of the data the tab displays.
User Sessions
URL Mangling
Port Forwarding
CIFS
Full Tunnel
