Chapter 42 Viewing Router Information

Traffic Status

Netflow Top Talkers

Note

Top Protocols

OL-4015-12
This window displays a tree of traffic types that can be monitored on an interface.
Before any traffic type can be monitored, it must be enabled on at least one
interface.
You can choose one of the following traffic types from the Traffic Status tree:
Netflow Top Talkers
•
• QoS
Application/Protocol Traffic
•
This type uses Network-based application recognition (NBAR) to monitor
traffic.
If Netflow statistics have been enabled for at least one interface in Configure >
Interfaces and Connections > Edit Interface/Connection, you can view
Netflow statistics. Choose Top N Traffic Flows > Top Protocols or Top N
Traffic Flows > Top Talkers (high-traffic sources) from the Traffic Status tree.
If the router Cisco IOS image does not support Netflow, the Netflow choices will
not be available in the Traffic Status tree.
This window displays a table with the following columns:
Protocol—Protocol being examined.
•
Total Flows—Total number of flows associated with that protocol.
•
Flows/Sec—Active flows per second for the protocol.
•
Packets/Flow—Packets transmitted per flow.
•
Bytes/Packet—Bytes per transmitted packet.
•
Packets/Sec—Packets transmitted per second.
•
