Firewall Log - Cisco ROUTER-SDM-CD User Manual

Logging
Search Button

Firewall Log

Firewall Log
Number of Attempts Denied by Firewall
Attempts Denied by Firewall Table
Cisco Router and Security Device Manager 2.5 User's Guide
42-32
Opens a search window. In the search window, enter text in the Search field and
click the Find button to display all entries containing the search text. Searches are
not case sensitive.
The log entries shown in the top part of this window are determined by log
messages generated by the firewall. In order for the firewall to generate log
entries, you must configure individual access rules to generate log messages when
they are invoked. For instructions on configuring access rules to cause log
messages, see the help topic
In order for firewall log entries to be collected, you must configure logging for the
router. Go to Additional Tasks > Router Properties > Logging. Click Edit, and
configure logging. To obtain firewall logging messages, you must configure a
logging level of debugging (7).
The firewall log is displaed if the router is configured to maintain a log of
connection attempts denied by the firewall.
Shows the number of connection attempts rejected by the firewall.
Shows a list of connection attempts denied by the firewall. This table includes the
following columns:
Time column
•
Shows the time that each denied connection attempt occurred.
Description column
•
Contains the following information about the denied attempt: log name,
access rule name or number, service, source address, destination address, and
number of packets. An example follows:
Chapter 42
How Do I View Activity on My Firewall?
Viewing Router Information
OL-4015-12
