Class Maps
Add
Edit
Delete
Class Map Area
Cisco Router and Security Device Manager 2.5 User's Guide
37-10
Click Add to create a new class map of the type you have selected and enter the
configuration in the displayed dialog.
Click Edit to change the configuration of the selected class map.
Click Delete to remove the selected class map. Cisco SDM may display dialogs
if there are dependencies associated with this configuration, such as subordinate
class maps or parameter maps that could be used by other class maps.
This area displays the class maps configured for the protocol that you selected. It
contains the names of the configured class maps and other relevant information.
QoS Class Maps
QoS class maps are displayed in a table with a Class Map Name and a Description
column. A sample table follows.
Class Map Name
CMAP-DMZ
CMAP-3
Inspection, HTTP, SMTP, SUN RPC, IMAP and POP3 Class Maps
These types of class maps have a Class Map Name and a Used By column A
sample table for HTTP follows.
Class Map Name
http-rqst
http-rsp-body
Chapter 37 Cisco Common Classification Policy Language
Description
FTP and HTTP QoS class map
Test
Used By
pmap-5
pmap-5
