Interface Status

Interface Status
Monitor Interface and Stop Monitoring Button
Test Connection Button
Cisco Router and Security Device Manager 2.5 User's Guide
42-6
High Severity
The number of log entries stored that have a severity level of 2 or lower. These
messages require immediate attention. Note that this list will be empty if you have
no high severity messages.
Warning
The number of log entries stored that have a severity level of 3 or 4. These
messages may indicate a problem with your network, but they do not likely
require immediate attention.
Informational
The number of log entries stored that have a severity level of 6 or higher. These
information messages signal normal network events.
The Interface Status screen displays the current status of the various interfaces on
the router, and the numbers of packets, bytes, or data errors that have travelled
through the selected interface. Statistics shown on this screen are cumulative since
the last time the router was rebooted, the counters were reset, or the selected
interface reset.
Click this button to start or stop monitoring the selected interface. The button
label changes based on whether Cisco SDM is monitoring the interface or not.
Click to test the selected connection. A dialog appears that enables you to specify
a remote host to ping through this connection. The dialog then reports on the
success or failure of the test. If the test fails, information about why the test may
have failed is given, along with the steps you need to take to correct the problem.
Chapter 42 Viewing Router Information
OL-4015-12
