Chapter 37 Cisco Common Classification Policy Language

Add or Edit a QoS Class Map

Add or Edit a QoS Class Map

Select a Class Map

Deep Inspection

Class Map and Application Service Group Windows

OL-4015-12
Use this information to help add or edit a QoS class map. If you are adding a new
QoS class map, click the button on the right of the field and choose either Add a
Classmap or Select a Classmap from the context menu.
See the information in
options.
Enter a name and description of the QoS class Map you are creating so that it can
be easily identified and used. Click
All, and Edit buttons in the Classification box.
Click the name of the class map that you want to choose, and click OK. The class
map entry is added to the window from which you invoked this dialog.
Deep inspection allows you to create class maps for parameters specific to an
application. For example, you can create class maps for the common
applications such as eDonkey, gnutella, and kazaa2.
Use the class map windows to review, create, and edit class maps for protocols
such as HTTP, SMTP, and POP3. The Class Map area of the window lists the
configured class maps, and the bottom part displays the details for the selected
class map. To edit a class map or see more detail, click Edit to display a dialog
that lets you view information and make changes.
Cisco Router and Security Device Manager 2.5 User's Guide
Action to learn about the Drop, Set DSCP, and Queuing
Classification
Class Maps
for a description of the Any,
P2P
37-9
