Labrie AUTOMIZER Helping Hand Operator's Manual page 97

Cab Dashboard
The following is a description of the controls and indicator lights on the dashboard.
Parking Brake
The parking brake must be applied every time the A
time.
Figure 3-46 Parking brake button
A E
RM XTENDED
1 or 2 A E
RM
they indicate that the automated arm is not completely retracted alongside the hopper. Do not move
the vehicle in such a situation. Retract the arm until those lights stop flashing before moving the
vehicle.
Figure 3-47 Arm Extended warning lights
: The above picture is for illustration purpose only. It shows a cab setup that may be different
N
OTE
from the one installed on your truck.
Warning!
Part # 200277 (rev.00.10.2024)
Warning Lights
warning lights are found on the cab dashboard. When those lights are flashing,
XTENDED
Never drive this vehicle if the automated arm is not parked alongside the truck. The unit
would be too high and/or too wide to be driven safely. Failure to retract the arm could
result in unit and/or property damage, personal injury or even death. The A
warning lights flash when the arm is not retracted completely.
is parked for an extended period of
UTOMIZER
Controls and Indicators 85
RM EXTENDED
